Rack Mounted 51.2V – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Fri, 30 May 2025 10:30:02 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 LP2900 White Series (51.2V-100/200Ah) https://www.mustpower.com/product/lp2900-white-series-51-2v-100-200ah/ Mon, 07 Oct 2024 08:07:30 +0000 https://www.mustpower.com/?post_type=product&p=24611 Lithium Iron Phosphate (LiFePO4) Battery 5.12-10.24kWh This battery is designed and manufactured by MUST for energy storage applications. It has long service life, high safety, flexible installation, strong expansibility and strong communication ability. It can be used in conjunction with MUST or many other brands of on/off grid inverters and EMS, and can also be equipped with WIFI modules to achieve wireless transmission and communication between devices, forming a complete energy storage system. The design of the battery meets the requirements of UN38.3, CE, IEC62619 and other standards for energy storage battery.]]> ■ 19 inches rack standard
■ Standard warranty: 10 years
■ A simpler stacking bracket can be used to form a battery system (optional)
■ Built-in WiFi Smart BMS Module
■ 7000 cycles @ 80% DOD, 25°C
■ Large capacity, high power output
■ Safest lithium iron phosphate battery cell with high energy density
■ Supports up to 16 units in parallel
■ High integration, saving installation cost and simplifying the wiring
■ Built-in circuit breaker for over-current protection
■ Perfect compatibility: support CAN & RS485 communication with mainstream inverters

Technical Data LP29-48100 LP29-48200
Nominal Voltage 51.2V
Nominal Capacity 100Ah 200Ah
Nominal Energy 5120Wh 10240Wh
AC Internal Impedance ≤30.0mΩ
Standard Charging Constant current 50.0A 100.0A
Constant voltage 56.8V 56.8V
End current (Cut off) 5A 10A
Standard Discharging Constant current 50A 150A
Cut off voltage 43.2V 43.2V
Charging Voltage Range 56.8~57.6V 56.8~57.6V
Max. Continuous Charging Current 100.0A 150.0A
Max. Output Power 5KW 7.5KW
Parallel connection Up to 16 units
Communication Port RS485, CAN, WIFI(optional)
Power cable connectors ESS-120A-25-B/S
Operation Temperature Charging temperature 0~50°C
Discharging temperature -10~50°C
Relative Humidity 5%~95% (No Condensation)
Storage Temperature -5°C~35°C
Installation Mode Rack (19”) installation Rack (19”) installation
Machine Dimension (W*H*D (mm) 440*133*470 /
Package Dimension (W*H*D) (mm) / /
N.W (kg) ≈44.5 /
G.W (kg) / /
* Variations in dimensions and weights may occur due to production batches.
Altitude ≤4000m
Warranty 10 years
Certification & Standards CE-EMC(EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019); IEC62619:2017; IEC62619:2022; UN38.3/ MSDS
]]> LP2900 Black Series (51.2V-100/200Ah) https://www.mustpower.com/product/lp2900-black-series-51-2v-100-200ah/ Tue, 23 Apr 2024 10:36:49 +0000 https://www.mustpower.com/?post_type=product&p=24126 Lithium Iron Phosphate (LiFePO4) Battery 5.12-10.24kWh This battery is designed and manufactured by MUST for energy storage applications. It has long service life, high safety, flexible installation, strong expansibility and strong communication ability. It can be used in conjunction with MUST or many other brands of on/off grid inverters and EMS, and can also be equipped with WIFI modules to achieve wireless transmission and communication between devices, forming a complete energy storage system. The design of the battery meets the requirements of UN38.3, CE, IEC62619 and other standards for energy storage battery.]]> ■ 19 inches rack standard
■ Standard warranty: 10 years
■ A simpler stacking bracket can be used to form a battery system (optional)
■ Built-in WiFi Smart BMS Module
■ 7000 cycles @ 80% DOD, 25°C
■ Large capacity, high power output
■ Safest lithium iron phosphate battery cell with high energy density
■ Supports up to 16 units in parallel
■ High integration, saving installation cost and simplifying the wiring
■ Built-in circuit breaker for over-current protection
■ Perfect compatibility: support CAN & RS485 communication with mainstream inverters

Technical Data LP29-48100 LP29-48200
Nominal Voltage 51.2V
Nominal Capacity 100Ah 200Ah
Nominal Energy 5120Wh 10240Wh
AC Internal Impedance ≤30.0mΩ
Standard Charging Constant current 50.0A 100.0A
Constant voltage 56.8V 56.8V
End current (Cut off) 5A 10A
Standard Discharging Constant current 50A 150A
Cut off voltage 43.2V 43.2V
Charging Voltage Range 56.8~57.6V 56.8~57.6V
Max. Continuous Charging Current 100.0A 150.0A
Max. Output Power 5KW 7.5KW
Parallel connection Up to 16 units
Communication Port RS485, CAN, WIFI(optional)
Power cable connectors ESS-120A-25-B/S
Operation Temperature Charging temperature 0~50°C
Discharging temperature -10~50°C
Relative Humidity 5%~95% (No Condensation)
Storage Temperature -5°C~35°C
Installation Mode Rack (19”) installation Rack (19”) installation
Machine Dimension (W*H*D (mm) 440*133*470 /
Package Dimension (W*H*D) (mm) / /
N.W (kg) ≈44.5 /
G.W (kg) / /
* Variations in dimensions and weights may occur due to production batches.
Altitude ≤4000m
Warranty 10 years
Certification & Standards CE-EMC(EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019); IEC62619:2017; IEC62619:2022; UN38.3/ MSDS
]]> LP1600 Rack-mounted (25.6/51.2V-100/200/300Ah) https://www.mustpower.com/product/lp1600-wall-mounted-25-6-51-2v-100-200-300ah-2/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23950 Rack-Mountable Design 25.6V & 51.2V | 2.56kWh ~ 10.24kWh Flexible, compact, and installation-friendly — this LP1600 variant is designed with three adaptable mounting options: wall-mounted, stacked-mounted (up to 5 units), or rack-mounted. Perfect for homes, telecom setups, and light commercial energy storage, it allows users to optimize space without compromising on performance. ]]> 🔧 Voltage & Capacity Options:
25.6V: 100Ah / 200Ah / 300Ah → 2.56 / 5.12 / 7.68 kWh
51.2V: 100Ah / 200Ah → 5.12 / 10.24 kWh

✅ Key Features:
All-in-one 3-in-1 design: Wall-mounted, Stacked, or Rack-mounted
Modular: Up to 40 units in parallel
Max output power: 2.5KW to 5KW
Smart WiFi BMS with LCD display
Long lifespan: 6000+ cycles @ 80% DOD, 25°C
CAN & RS485 communication compatibility
Sleek and durable casing for modern energy setups
Ideal for residential solar systems, mobile stations, backup energy needs

⚡ Ideal For
• Residential solar ESS
• Commercial backup systems
• Off-grid power stations
• Modular rack systems and hybrid inverter setups
The LP1600 Series brings safety, scalability, and smart control into one powerful energy storage solution — made to evolve with your energy needs.

Technical Data LP16-24100 LP16-24200 LP16-24300 LP16-48100 LP16-48200 LP16-48300 LP16-48320
Nominal Voltage 25.6V 51.2V
Nominal Capacity 100Ah 200Ah 300Ah 100Ah 200Ah 300Ah 320Ah
Nominal energy 2560Wh 5120Wh 7680Wh 5120Wh 10240Wh 15360Wh 16384Wh
Max. output power 2.5KW 3.5KW 5KW 5KW 7.5KW 10KW 7.5KW
Life Cycles 6000 cycles @ 80% DOD, 25°C
Recommended Charge Voltage 29.2V 58.4V
Recommended Charge Current 20A 40A 60A 20A 40A 60A 60A
End Of Discharge Voltage 22V 44V
Standard Method Charge 20A 40A 60A 20A 40A 60A 60A
Discharge 50A 100A 150A 50A 100A 150A 100A
Maximum Continuous Current Charge 100A 150A 200A 100A 150A 200A 150A
Discharge 100A 150A 200A 100A 150A 200A 150A
BMS Cut-Off Voltage Charge 29.2 V (3.65V/Cell) 58.4 V (3.65V/Cell)
Discharge 22.0V (2s) (2.75V/Cell) 44.0V (2.75V/Cell)
Temperature Charge 0~50°C
Discharge -20~60°C
Storage Temperature -5~35°C
Shipment Voltage ≥25.6V ≥51.2V
Safety Function Over-charge, Over-discharge, Over-current, Low/High-temperature, Short-circuit Protections
Module Parallel Up to 40 units
Communication CAN2.0/RS232/RS485
IP Protection level IP21
Case Material SPCC
Installation Mode Wall-mounted, Stacked-mounted, Rack-mounted(optional) Vertical-mounted
Machine Dimension (W*H*D) (mm) 442*485.5*177 442*486.5*250 442*495*230 442*625.5*177 442*686.5*250 490*923*265
Package Dimension (W*H*D) (mm) carton box 557*227*547 557*300*547 / 688*227*557 non /
wooden box 555*340*565 555*410*565 600*570*405 700*570*350 759*405*569 1000*450*565
N.W (kg) 27 44 68 45 80 117
G.W (kg) carton box 30 48 / 48 non /
wooden box 40 57 85 58 97 137
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention
rate≥90%, Recovery rate of charge≥90%
Warranty 5 years
Certification & Standards CE-EMC (EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019) IEC62619-1:2018; IEC62619:2022; IEC62619:2017; UN38.3/ MSDS
]]> LP1800 Series (25.6/51.2V-100/200Ah) https://www.mustpower.com/product/lp1800-series-25-6-51-2v-100-200ah/ Wed, 06 Mar 2024 11:29:41 +0000 https://www.mustpower.com/?post_type=product&p=23871 LiFePO4 Battery 5120Wh 10240Wh MUST's 19 inches rack standard backup battery is based on Lithium iron phosphate battery, It has been designed to provide backup power for telecom equipment or energy storage system in household. It has excellent safety, high energy density, long lifetime, very nice temperature performance, green power newly of excellent safety and high reliability.]]> ■ 6000 cycles @ 80% DOD, 25°C for effectively lower total of ownership cost
■ Integrated battery management system (BMS)
■ Safest lithium iron phosphate battery cell with high energy density
■ Modular design: LP1800 supports up to 15 units in parallel
■ 19 inches rack standard design, saving installation space
■ High integration, saving installation cost and simplifying the wiring
■ Perfect compatibility: support CAN & RS485 communication with mainstream inverters
■ Built-in WiFi Smart Module

Technical Data LP18-24200 LP18-48100 LP18-48200
Nominal Voltage 25.6V 51.2V
Nominal Capacity 200Ah 100Ah 200Ah
Nominal energy 5120Wh 5120Wh 10240Wh
Max. output power 3.5KW 5KW 7.5KW
Life Cycles 6000 cycles @ 80% DOD, 25°C
Recommended Charge Voltage 29.2V 58.4V
Recommended Charge Current 40A 20A 40A
End Of Discharge Voltage 22V 44V
Standard Method Charge 40A 20A 40A
Discharge 100A 50A 100A
Maximum Continuous Current Charge 150A 100A 150A
Discharge 150A 100A 150A
BMS Cut-Off Voltage Charge 29.2 V (3.65V/Cell) 58.4 V (3.65V/Cell)
Discharge 22.0V(2.75V/Cell) 32.0V(2.0V/Cell)
Temperature Charge 0~ 45°C
Discharge -10~55°C
Storage Temperature -5~35°C
Shipment voltage ≥25.6V ≥51.2V
Module Parallel Up to 15 units
Communication CAN2.0/RS232/RS485
IP Protection level IP21
Case Material SPCC
Machine Dimension (W*H*D) (mm) 486.5*225*479 625.5*152*479 686.5*225*479
Package Dimension (W*H*D) (mm) carton box 557*301*547 688*227*557 non
wooden box 555*410*565 696*335*565 759*391*569
N.W (kg) 44 45 80
G.W (kg) carton box 48 48 non
wooden box 57 58 97
* Variations in dimensions and weights may occur due to production batches.
Charge Retention And Capacity Recovery Capability Standard charge the battery, and then put aside at room temperature for 28d or 55°C for 7d, Charge retention
rate≥90%, Recovery rate of charge≥90%
Warranty 5 years
Certification & Standards CE-EMC(EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019); IEC62619:2017; IEC62619:2022; UN38.3/ MSDS
]]>
