Description
■ 19 inches rack standard
■ Standard warranty: 10 years
■ A simpler stacking bracket can be used to form a battery system (optional)
■ Built-in WiFi Smart BMS Module
■ 7000 cycles @ 80% DOD, 25°C
■ Large capacity, high power output
■ Safest lithium iron phosphate battery cell with high energy density
■ Supports up to 16 units in parallel
■ High integration, saving installation cost and simplifying the wiring
■ Built-in circuit breaker for over-current protection
■ Perfect compatibility: support CAN & RS485 communication with mainstream inverters
| Technical Data | LP29-48100 | LP29-48200 | |
| Nominal Voltage | 51.2V | ||
| Nominal Capacity | 100Ah | 200Ah | |
| Nominal Energy | 5120Wh | 10240Wh | |
| AC Internal Impedance | ≤30.0mΩ | ||
| Standard Charging | Constant current | 50.0A | 100.0A |
| Constant voltage | 56.8V | 56.8V | |
| End current (Cut off) | 5A | 10A | |
| Standard Discharging | Constant current | 50A | 150A |
| Cut off voltage | 43.2V | 43.2V | |
| Charging Voltage Range | 56.8~57.6V | 56.8~57.6V | |
| Max. Continuous Charging Current | 100.0A | 150.0A | |
| Max. Output Power | 5KW | 7.5KW | |
| Parallel connection | Up to 16 units | ||
| Communication Port | RS485, CAN, WIFI(optional) | ||
| Power cable connectors | ESS-120A-25-B/S | ||
| Operation Temperature | Charging temperature | 0~50°C | |
| Discharging temperature | -10~50°C | ||
| Relative Humidity | 5%~95% (No Condensation) | ||
| Storage Temperature | -5°C~35°C | ||
| Installation Mode | Rack (19”) installation | Rack (19”) installation | |
| Machine Dimension (W*H*D (mm) | 440*133*470 | / | |
| Package Dimension (W*H*D) (mm) | / | / | |
| N.W (kg) | ≈44.5 | / | |
| G.W (kg) | / | / | |
| * Variations in dimensions and weights may occur due to production batches. | |||
| Altitude | ≤4000m | ||
| Warranty | 10 years | ||
| Certification & Standards | CE-EMC(EN 61000-6-3: 2007+A1: 2011+AC: 2012 EN IEC 61000-6-1: 2019); IEC62619:2017; IEC62619:2022; UN38.3/ MSDS | ||
