Rack Inverter – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Tue, 12 Nov 2024 09:05:52 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 EP5000 PRO Rack Series (5.2KW) https://www.mustpower.com/product/ep5000-pro-rack-series-5-2kw/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23961 High Frequency Inverter 5.2KW | 230V | WIFI This is a multi-function inverter/charger ,combining Functions of inverter, battery charger to offfer uninte uninterruptible power with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC charger, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter
■ Configurable input voltage range For home appliances and personal computers via LCD setting Configurable battery charging current based on applications via LCD setting
■ Configurable AC Charger via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/Over temperature/short circuit protection
■ Smart battery charger design For optimized battery performance
■ Cold start Function
■ WIFI remote monitoring (optional)

MODEL EP50-5248 PRO
Rated output power 5200VA/5200W
AC INPUT
Nominal Input Voltage 230Vac±5%
Selectable Voltage range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105)
Frequency Range 50Hz/60Hz (Auto sensing)
Inverter Efficiency(Peak) 90%
INVERTER OUTPUT
Output voltage waveform Pure sine wave
Output Voltage Regulation 230Vac ± 5%
Output Frequency 50Hz / 60Hz(Auto sensing)
Power Factor ≈1
Transfer Time 10ms (UPS / VDE4105) / 20ms (APL) （50ms(For parallel operation)
Nominal DC Input Voltage 48VDC
Cold Start Voltage 46VDC
Output Short Circuit Protection Line mode Circuit Breaker
Battery mode Electronic Circuits
BATTERY
Battery voltage 48VDC
Floating voltage 54.8V
Overcharge Protection 60V
CHARGER
Charging Current(UPS) @Nominal Input Voltage Default:30A; MAX:80A
Bulk Charging Voltage 56.4Vdc
Floating Charging Voltage 54Vdc
Charging Algorithm 3-Step
GENERAL
Mounting Rack mount
Display LED+LCD
Parallel operation 3 units
Operation Temperature Range -10°C to 50°C
Storage Temperature -15°C to 60°C
Machine Dimension (W*H*D) 468*86.3*400mm
Package Dimension (W*H*D) /
N.W 11kg
G.W /
CERTIFICATION & STANDARDS
CE
]]> PV5000 PRO Rack Series (3-5.2KW) https://www.mustpower.com/product/pv5000-pro-rack-series-3-5-2kw/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23962 High Frequency Solar Inverter PV 450V | MPPT 80/100A | WIFI | BAT-CAN PV5000 PRO is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV5000 PRO Series can run without battery. The Maximum PV array open circuit voltage can reach 450V and MPPT voltage is 150~430Vdc, which Can help customers make full use of solar energy.]]> ■ Pure sine wave inverter

■ Configurable input voltage range for home appliances and personal computers via LCD setting

■ Configurable battery charging current based on applications via LCD setting

■ Configurable AC/Solar Charger priority via LCD setting

■ Compatible to mains voltage or generator power

■ Auto restart while AC is recovering

■ Overload/ Over temperature/ short circuit protection

■ Smart battery charger design for optimized battery performance

■ Cold start function

■ Parallel operation with up to 3 units

■ WIFI remote monitoring (optional)

MODEL PV50-3048 PRO PV50-4048 PRO PV50-5248 PRO
Nominal Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 3000VA / 3000W 5200VA / 5200W 5200VA / 5200W
Surge Power 6000W 8000W 10400W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 90%
Transfer Time 10ms (UPS / VDE4105) / 20ms (APL)
AC INPUT
Voltage 230VAC±5%
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105)
Frequency Range 50Hz / 60Hz(Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 450VDC
Maximum PV input voltage 18A 18A 27A
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 4000W 5000W 6000W
PV Array MPPT Voltage Range 150~430 VDC
Maximum Solar Charge Current 80A 80A 100A
Maximum AC Charge Current 60A 60A 80A
Maximum Charge Current 80A 80A 100A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 468*86.3*400
Package Dimension (W*H*D)(mm) 546*185*540
N.W(kg) 12.5
G.W(kg) 14
Warranty 2years
OTHER
Parallel operation 3 units
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature 0°C~50°C
Storage Temperature -25°C~60°C
CERTIFICATION & STANDARDS
CE/IEC
]]> EP5000 Rack Series (3-5KW) https://www.mustpower.com/product/ep5000-rack-series-3-5kw/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23925 High Frequency Pure sine Wave Power inverter 3~5KW | 230V | BAT-CAN This is a multi-function inve inverter/charger ,combining Functions of inverter, battery charger to offfer uninte uninterruptible power with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC charger, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter

■ Configurable input voltage range For home appliances and personal computers via LCD setting Configurable battery charging current based on applications via LCD setting

■ Configurable AC Charger via LCD setting

■ Compatible to mains voltage or generator power

■ Auto restart while AC is recovering

■ Overload/Over temperature/short circuit protection

■ Smart battery charger design For optimized battery performance

■ Cold start Function

MODEL EP50-3KW EP50-4KW EP50-5KW
Rated output power 3000W 4000W 5000W
AC INPUT
Nominal Input Voltage 230Vac±5%
Selectable Voltage range AC 185V~270V
Frequency Range 50Hz/60Hz (Auto sensing)
Inverter Efficiency(Peak) 97%
INVERTER OUTPUT
Output voltage waveform Pure sine wave
Output Voltage Regulation 220Vac ± 5%
Output Frequency 50Hz
Power Factor 1
Transfer Time 10ms typical
Peak Efficiency 92%
Nominal DC Input Voltage 48VDC
Cold Start Voltage 46VDC
Output Short Circuit Protection Line mode Circuit Breaker
Battery mode Electronic Circuits
BATTERY
Battery voltage 48VDC ( ±0.5)
Floating voltage 54V
CHARGER
Charging Current(UPS) @Nominal Input Voltage Default:30A; MAX:60A
Bulk Charging Voltage 56.4Vdc
Floating Charging Voltage 54Vdc
Charging Algorithm 3-Step
GENERAL
Mounting Rack mount
Display LED+LCD
Parallel operation 3 units
Operation Temperature Range 0°C to 40°C
Storage Temperature -15°C to 60°C
Machine Dimension (W*H*D) 468*86.3*400mm
Package Dimension (W*H*D) /
N.W /
G.W /
CERTIFICATION & STANDARDS
CE
]]> PV5000 Rack Series (3-5KW) https://www.mustpower.com/product/pv5000-rack-series-3-5kw/ Wed, 06 Mar 2024 11:29:35 +0000 https://www.mustpower.com/?post_type=product&p=23850 High Frequency Rack-Mount Solar Inverter 3~5KW | PV 145V | DC 48V | MPPT 80A This is a multi-function inverter/charger, combining functions of inverter, solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easyaccessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter
■ Configurable input voltage range for home appliances and personal computers via LCD setting
■ Configurable battery charging current based on applications via LCD setting
■ Configurable AC/Solar Charger priority via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/ Over temperature/ short circuit protection
■ Smart battery charger design for optimized battery performance
■ Cold start function
■ Built-in MPPT solar charge controller 80A
■ WIFI remote monitoring (optional)

MODEL PV50-3K PV50-4K PV50-5K
Nominal Battery System Voltage 48V
INVERTER OUTPUT
Rated Output Power 3KW 4KW 5KW
Surge Power 6KW 8KW 10KW
Waveform Pure Sine Wave
Power factor 1
Output Voltage Regulation 230Vac±5%
Inverter Efficiency(Peak) 90%
Transfer Time 10ms typical (UPS / VDE4105) 20ms typical (APL)
AC INPUT
Nominal Input Voltage 230VAC
Selectable voltage range 170~280VAC(UPS), 90~280VAC(APL) , 184~253VAC(VDE4105)
Input Voltage Waveform Sinusoidal (utility or generator)
Frequency Range 50Hz / 60Hz
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 145VDC
MPPT Range @ Operating Voltage 60~130VDC
Standby Power Consumption 2W
Maximum PV Array Power 4000W
Maximum PV Charge Current: 80A
Maximum Efficiency 98%
Maximum AC Charge Current 60A
Maximum Charge Current(PC+AC) 80A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 468*86.3*400
Package Dimension (W*H*D)(mm) /
N.W (kg) 10
G.W (kg /
OTHER
Parallel operation 3 units
Operating Temperature Range -10°C ~ 40°C
Storage temperature -15°C~ 60°C
CERTIFICATION & STANDARDS
CE, EN IEC62368-1
]]>
