Low Frequency Inverter – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Tue, 12 Nov 2024 09:46:42 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 PV3900 Series (8-12KW) https://www.mustpower.com/product/pv3900-series-8-12kw/ Fri, 24 May 2024 07:16:06 +0000 https://www.mustpower.com/?post_type=product&p=24292 Low Frequency Solar Inverter DC 48V | PV 250V | MPPT 100/200A PV3900 Series is a multi-function inverter ,combining functions of inverter and MPPT solar charger controller, solar charger and battery charger to offer uninterruptible power support. The comprehensive LCD display offers userconfigurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and selectable input voltage based on different applications.]]> ■ Smart LCD setting(Working modes, Charge Current, Charge voltage, etc.)
■ Built-in MPPT solar charge controller 100A/200A
■ MPPT efficiency max 98%
■ Powerful charge rate up to 200A
■ Inside BMS function
■ DC start &Automatic Self-Diagnostic Function
■ WIFI monitoring function (optional)
■ Compatible to generator
■ Parallel operation with up to 3 units

MODEL PV3900-8048 PV3900-10048 PV3900-12048
Nominal Battery System Voltage 48VDC
Stand-alone mode Yes
Parallel operation 3 units
INVERTER OUTPUT
Rated power 8KW 10KW 12KW
Surge rating 24000VA 30000VA 36000VA
Capable of starting electric motor 4HP 5HP 6HP
Waveform Pure sine wave / same as input (bypass mode)
Nominal output voltage RMS 220V/230V/240V
Inverter efficiency (peak) >88%
Line mode efficiency >95%
Power factor 1.0
Typical transfer time 10ms(max)
AC INPUT
Voltage 220V/230V/240V
Selectable voltage range 90-280 VAC (APL)
Frequency range 50Hz / 60Hz
BATTERY
Low battery voltage cutoff 40-48VDC for 48VDC mode
Low battery voltage recover 42-50VDC for 48VDC mode
High battery voltage cutoff 60VDC for 48VDC mode
High battery voltage recover 57VDC for 48VDC mode
AC CHARGER
Output voltage Depends on battery type (Supports lead-acid, gel, and lithium batteries)
Charger AC input breaker rating 100A
Overcharge protection S.D. 62.8VDC for 48VDC mode
Maximum charge current 10-140A (setting) battery terminal
BTS
Continuous output power Yes Variances in charging voltage & S.D. voltage base on the battery temperature
BYPASS & PROTECTION
Input voltage waveform Sine wave (grid or generator)
Nominal input frequency 50Hz or 60Hz
Overload protection (SMPS Load) Software + Circuit breaker
Output short circuit protection Software + Circuit breaker
Bypass breaker rating 63A
Max bypass current 80A
SOLAR CHARGER
Maximum PV charge current 100A 200A 200A
DC voltage 48V
Maximum PV array power 5000W 10000W 10000W
MPPT range @ operating voltage(VDC) 64~235VDC
Maximum PV array open circuit voltage 250VDC
Maximum efficiency >98%
Standby power consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall mount
Packing Wooden box
Machine Dimension (W*H*D)(mm) 439*660.5*223
Package Dimension (W*H*D)(mm) 782*304*520.5
N.W(kg) 59 68 75
G.W(kg) 76 85 92
Warranty 2years
OTHER
Operating temperature range 0°C to 50°C
Storage temperature 15°C to 60°C
Audible noise 60dB MAX
Communication WiFi
Display LED+LCD
CERTIFICATION & STANDARDS
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011)
]]> PV2900 HP Series (1-6KW) https://www.mustpower.com/product/pv2900-hp-series-1-6kw/ Wed, 24 Apr 2024 03:48:41 +0000 https://www.mustpower.com/?post_type=product&p=24155 Low Frequency Inverter 1~6KW | AC 230V | MPPT 80A | PV 245V PV2900 HP series is very economical pure sine wave solar inverter, Inbuilt with 80A MPPT charger; Solar/AC priority is configurable, when setting solar priority, solar will charge batteries as first priority, and AC can also charge batteries when solar charger current is too lower, in this way system charge is optimazed best. it enables inverter to operate with all kinds of home appliances.]]> ■ 3 Steps charging
■ Overload and short-circuit protection
■ Set charging voltage/charging current
■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5/12V
■ Power-save mode
■ Set utility priority /battery priority
■ Set utility input wide/narrow voltage range
■ Inverter voltage can be set to 220V/230V/240V
■ Inverter frequency can be set to 50Hz/60Hz
■ Set utility charging on/off switch
■ Inbuilt 80A MPPT Solar Charge Controller
■ Acid or Lithium Select
■ WIFI remote monitoring (optional)
■ With BMS lithium battery communication function (CAN port)
■ Dual output for smart load management

MODEL PV29-1KW-HP PV29-1.5KW-HP PV29-2KW-HP PV29-3KW-HP PV29-4KW-HP PV29-5KW-HP PV29-6KW-HP
Nominal Battery System Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 24VDC 48VDC 24VDC 48VDC 48VDC 48VDC
INVERTER OUTPUT
Rated Power 1 KW 1.5 KW 2 KW 3 KW 4 KW 5 KW 6 KW
Surge Rating 3000VA 4500VA 6000VA 9000VA 12000VA 15000VA 18000VA
Capable Of Starting Electric Motor 1P 1P 1.5P 2P 3P
Waveform Pure sine wave / same as input (bypass mode)
Nominal Output Voltage RMS 220V / 230V / 240VAC (±10% RMS)
Output Frequency 50Hz / 60Hz ±0.3Hz
Inverter Efficiency (Peak) >88%
Line Mode Efficiency >95%
Power Factor 1.0
Typical Transfer Time 10ms(max)
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 155~265VAC(For personal computers)
Frequency Range 50Hz / 60Hz(Auto sensing) 40~80Hz
BATTERY
Minimum Start Voltage (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Alarm (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Cut Off 10V / 10.5V / 11V / 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Alarm (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Energy Saving Mode Load ≤50±20W(120V)/100±20W(220V)
CHARGER
Output Voltage Depends on battery type
Overcharge Protection S.D. 15.5VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode)
Maximum Charge Current 30A 20A 45A 25A 60A 30A 40A 20A 60A 30A 35A 40A
PAYPASS & PROTECTION
Input Voltage Waveform Sine wave (grid or generator)
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load) Circuit breaker
Output Short Circuit Protection Circuit breaker
AC Input Breaker 1-3K/30A 4-6K/50A
SOLAR CHARGER
Maximum PV Array Power 1250W 2500W 1250W 2500W 1250W 2500W 2500W 5000W 2500W 5000W 5000W 5000W
Maximum PV Charge Current 80A±4A
DC Voltage 12V/ 24V auto work 24V/ 48V auto work
MPPT Range @ Operating Voltage 15~95VDC @ 12V/ 30~230VDC @ 24V 30~230VDC @ 24V/ 60~230VDC @ 48V
Maximum PV Array Open Circuit Voltage 245VDC
Standby Power Consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall Mount
Dimensions (W*H*D) 274*484*174mm 274*568.5*174mm
Package Dimensions (W*H*D) 583.5*376*255mm 668.5*376*255mm
N.W (kg) / /
G.W (kg) / /
OTHER
Operating Temperature Range 0°C ~ 40°C
Storage Temperature -15°C ~ 60°C
Audible Noise 60dB MAX
Display LED+LCD
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> PV3900 TLV Series (AC:110/220V 8-12KW) https://www.mustpower.com/product/pv3900-tlv-series-ac110-220v-8-12kw/ Wed, 06 Mar 2024 11:29:57 +0000 https://www.mustpower.com/?post_type=product&p=23970 Low Frequency Solar Inverter PV 250V | MPPT 200A |DC 48V PV3900 TLV series is a multi-function inverter ,combining functions of inverter and MPPT solar charger controller, solar charger and battery charger to offer uninterruptible power support. The comprehensive LCD display offers userconfigurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and selectable input voltage based on different applications.]]> ■ Smart LCD setting(Working modes, Charge Current, Charge voltage, etc.)
■ Built-in MPPT solar charge controller 200A
■ MPPT efficiency max 98%
■ Powerful charge rate up to 200A
■ Inside BMS function
■ DC start &Automatic Self-Diagnostic Function
■ WIFI monitoring function (optional)
■ Compatible to generator
■ Parallel operation with up to 3 units

MODEL PV39-8048 TLV PV39-10048 TLV PV39-12048 TLV
Nominal Battery System Voltage 48VDC
Stand-alone mode Yes
Parallel operation 3 units
INVERTER OUTPUT
Rated power 8KW 10KW 12KW
Surge rating 24000VA 30000VA 36000VA
Capable of starting electric motor 4HP 5HP 6HP
Waveform Pure sine wave / same as input (bypass mode)
Nominal output voltage RMS 100V/110V/120V/200V/220V/240V
Inverter effciency(peak) >90%
Line mode efficiency >95%
Power factor 1.0
Typical transfer time 10ms(max)
AC INPUT
Voltage 220V/230V/240V
Selectable voltage range 90-280 VAC (APL)
Frequency range 50Hz / 60Hz
BATTERY
Low battery voltage cutoff 40-48VDC for 48VDC mode
Low battery voltage recover 42-50VDC for 48VDC mode
High battery voltage cutoff 60VDC for 48VDC mode
High battery voltage recover 57VDC for 48VDC mode
No-load loss <50W
AC CHARGER
Output voltage Depends on battery type (Supports lead-acid, gel, and lithium batteries)
Charger AC input breaker rating 100A
Overcharge protection S.D. 62.8VDC for 48VDC mode
Maximum charge current 10-140A (setting) battery terminal
BTS
Continuous output power Yes Variances in charging voltage & S.D. voltage base on the battery temperature
BYPASS & PROTECTION
Input voltage waveform Sine wave (grid or generator)
Nominal input frequency 50Hz or 60Hz
Overload protection (SMPS Load) Software + Circuit breaker
Output short circuit protection Software + Circuit breaker
Bypass breaker rating 63A
Max bypass current 80A
SOLAR CHARGER
Maximum PV charge current 200A
DC voltage 48V
Maximim PV array power 10000W 10000W 10000W
MPPT range @ operating voltage(VDC) 64~235VDC
Maximum PV array open circuit voltage 250VDC
Maximum effciency >98%
Standby power consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall mount
Packing Wooden box
Machine Dimension (W*H*D)(mm) 439*660.5*233.2
Package Dimension (W*H*D)(mm) 782*314.5*520.5
N.W(kg) 55 62 69
G.W(kg) 73 80 87
OTHER
Operation temperature range 0°C to 50°C
Storage temperature 15°C to 60°C
Audible noise 60dB MAX
Communication WiFi
Display LED+LCD
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011); UL1741
]]> EP2000 Pro Black Series (DC:24V 300-1000W) https://www.mustpower.com/product/ep2000-pro-black-series-dc24v-300-1000w/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23947 Inverter Charger 300W~1000W | 24V | 5~15A EP2000 PRO series inverter is a cost effective, intelligent with UPS function. The comprehensive LCD offers user-configurable and easy-accessible button adjustment such as battery charge current, battery charge voltage, frequency, buzzer etc. It's perfect for the user who need a simple and economical inverter,with user-friendly installnation and setting.Tower and rack design available for different choices.]]> ■ Pure sine wave output

■ Smart LCD setting ( frequency , charge voltage,charge current, etc).

■ 3 steps charging algorithm

■ Built in AVR function

■ Overload and short-circuit protection

■ Battery reverse polarity protection (Optional)

■ Deep discharge protection

■ Cold start function

MODEL EP20-0312 PRO EP20-0612 PRO EP20-0812 PRO EP20-1012 PRO EP20-0324 PRO EP20-0624 PRO EP20-0824 PRO EP20-1024 PRO
Default Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated Power 300W 600W 800W 1000W 300W 600W 800W 1000W
Surge Rating 900VA 1800VA 2400VA 3000VA 900VA 1800VA 2400VA 3000VA
Waveform Pure sine wave
Voltage Regulation Battery mode: 220 or 230VAC Line mode: 220~240VAC
Output Frequency 50Hz / 60Hz
Inverter Frequency (Peak) >75% >81%
Bypass Efficiency >95%
Output Transfer Time Typical:8ms 12ms(max)
AC INPUT
Voltage 220 / 230 / 240VAC
Selectable Voltage Range 140~280VAC ±5%
Low Battery Alarm 140VAC ±5%
Low Voltage Recover 150VAC ±5%
High Battery Alarm 280VAC ±5%
High Voltage Recover 270VAC ±5%
Low Frequency Alarm 45 ±5Hz
Low Frequency Recover 46 ±5Hz
High Frequency Alarm 65 ±5Hz
High Frequncy Recover 64 ±5Hz
Nominal Input Range 50Hz / 60Hz ±5Hz
AC Auto Restart YES
BATTERY
Minimum Start Voltage Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low Battery Voltage Alarm Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low Battery Voltage Cut Off 10-12.0VDC 20.0-24.0VDC
High Battery Voltage Alarm (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC)
AC CHARGE
Floating Voltage 13.5-14.5VDC 27-29VDC
Boost Voltage 13.8~14.5VDC 27.6~29VDC
Maximum Charge Current 300W 600W 800W 1000W 300W 600W 800W 1000W
10A 20A 25A 30A 5A 10A 15A 15A
BYPASS & PROTECTION
Input Waveform Pure sine wave
Input Frequency 50Hz or 60Hz
Overload Protection 110%~125% Load foult affter 60s; 125%~150% Load foult affter 3s; >150% Load fault after 500ms
Over Temperature Protection ≥90°C
Bypass Output Protection 10A 250VAC
Output Circuit Protection YES
Battery Reverse Protection Optional
Battery Low Voltage Protection YES
Battery High Voltage Protection YES
Bypass Breaker Rating 10A
Maximum Bypass Current 10A
MECHANICAL SPECIFICATION
Machine Dimension (W*H*D)(mm) 315*145*210
N.W(kg) 300W 600W 800W 1000W 300W 600W 800W 1000W
7.5 10.7 12.5 13.5 7.5 10.7 12.5 13.5
Package Dimension (W*H*D)(mm) 420*280*225
G.W(kg) 300W 600W 800W 1000W 300W 600W 800W 1000W
8 11.5 13 14.0 8 11.5 13 14
OTHER
Operating Temperature 0°C~40°C 0~90% relative humidity (non-condensing)
Storage Temperature -15°C to 55°C
Altitude ≤1000M
Audible Noise ≤60dB
Display LED+LCD
Cooling Mode Fan cooling
Fan Starting >45°C starting, <30°C Closing
Communication USB
CERTIFICATION & STANDARDS
CE-LVD (EN IEC62109-1:2010,EN IEC62109-2:2011)
CE-EMC+LVD (EN6100-6-4:2007, EN6100-6-2:2005+EN IEC62109-1:2010, EN IEC62109-2:2011)
IEC60950-1:2005A+1:2009+A2:2013 EN IEC62040-1:2019
]]> PV3600 TLV Series (AC:110/220V 8-12KW) https://www.mustpower.com/product/pv3600-tlv-series-ac110-220v-8-12kw/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23942 Low Frequency Off Grid Solar Inverter 8~12KW | AC 120V/220V | DC 48V | PV 245V | MPPT 100A, 200A PV3600 TLV series is a multi-function inverter ,combining functions of inverter and MPPT solar charger controller, solar charger and battery charger to offer uninterruptible power support. The comprehensive LCD display offers userconfigurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and selectable input voltage based on different applications.]]> ■ Smart LCD setting(Working modes, Charge Current, Charge voltage, etc.)

■ Built-in MPPT solar charge controller 100A/200A

■ MPPT efficiency max 98%

■ Powerful charge rate up to 140Amp

■ Inside BMS function

■ DC start &Automatic Self-Diagnostic Function

■ WIFI / USB monitoring function (wi-fi optional)

■ Supporting AGS, BTS port

■ Compatible to generator

MODEL PV36-8048 TLV PV36-10048 TLV PV36-12048 TLV
Nominal Battery System Voltage 48VDC 48VDC 48VDC
INVERTER OUTPUT
Rated power 8.0KW 10.0KW 12.0KW
Surge rating 24000VA 30000VA 36000VA
Capable of starting electric motor 4HP 5HP 6HP
Waveform Pure sine wave / same as input (bypass mode)
Nominal output voltage RMS 100V/110V/120V/200V/220V/240V
Output frequency 50Hz / 60Hz ± 0.3Hz
Inverter effciency(peak) >88%
Line mode efficiency >95%
Power factor 1.0
Typical transfer time 20ms(max)
AC INPUT
Voltage 220V/230V/240V
Selectable voltage range 90-280 VAC (APL)
Frequency range 50Hz / 60Hz
BATTERY
Low battery voltage cutoff 40-48VDC for 48VDC mode
Low battery voltage recover 42-50VDC for 48VDC mode
High battery voltage cutoff 60VDC for 48VDC mode
High battery voltage recover 57VDC for 48VDC mode
Power saving mode <600W
AC CHARGER
Output voltage Depends on battery type
Charger AC input breaker rating 80A 80A 80A
Overcharge protection S.D. 62.8VDC for 48VDC mode
Maximum charge current 60A 70A 80A
BTS
Continuous output power Yes Variances in charging voltage & S.D. voltage base on the battery temperature
BYPASS & PROTECTION
Input voltage waveform Sine wave (grid or generator)
Nominal input frequency 50Hz or 60Hz
Overload protection (SMPS Load) Circuit breaker
Output short circuit protection Circuit breaker
Bypass breaker rating 63A 63A 63A
Max bypass current 80A
SOLAR CHARGER
Maximum PV charge current 100A/200A
DC voltage 48V
Maximim PV array power 5000W(10000W for 200A optional)
MPPT range @ operating voltage(VDC) 64~235VDC
Maximum PV array open circuit voltage 250VDC
Maximum effciency >98%
Standby power consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall mount
Machine Dimension (W*H*D)(mm) 402*674*222
Package Dimension (W*H*D)(mm) 818*415*577.5
N.W(kg) /
G.W(kg) /
OTHER
Operating Temperature Range 0°C to 50°C
Storage temperature -15°C to 60°C
Audible noise 60dB MAX
Display LED+LCD
Standard Warranty 2years
CERTIFICATION & STANDARDS
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011)
]]> EP2000 Pro Black Series (DC:12V 300-1000W) https://www.mustpower.com/product/ep2000-pro-black-series-dc12v-300-1000w/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23946 Inverter Charger 300W~1000W | 12V | 10~30A EP2000 PRO series inverter is a cost effective, intelligent with UPS function. The comprehensive LCD offers user-configurable and easy-accessible button adjustment such as battery charge current, battery charge voltage, frequency, buzzer etc. It's perfect for the user who need a simple and economical inverter,with user-friendly installnation and setting.Tower and rack design available for different choices.]]> ■ Pure sine wave output

■ Smart LCD setting ( frequency , charge voltage,charge current, etc).

■ 3 steps charging algorithm

■ Built in AVR function

■ Overload and short-circuit protection

■ Battery reverse polarity protection (Optional)

■ Deep discharge protection

■ Cold start function

MODEL EP20-0312 PRO EP20-0612 PRO EP20-0812 PRO EP20-1012 PRO EP20-0324 PRO EP20-0624 PRO EP20-0824 PRO EP20-1024 PRO
Default Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated Power 300W 600W 800W 1000W 300W 600W 800W 1000W
Surge Rating 900VA 1800VA 2400VA 3000VA 900VA 1800VA 2400VA 3000VA
Waveform Pure sine wave
Voltage Regulation Battery mode: 220 or 230VAC Line mode: 220~240VAC
Output Frequency 50Hz / 60Hz
Inverter Frequency (Peak) >75% >81%
Bypass Efficiency >95%
Output Transfer Time Typical:8ms 12ms(max)
AC INPUT
Voltage 220 / 230 / 240VAC
Selectable Voltage Range 140~280VAC ±5%
Low Battery Alarm 140VAC ±5%
Low Voltage Recover 150VAC ±5%
High Battery Alarm 280VAC ±5%
High Voltage Recover 270VAC ±5%
Low Frequency Alarm 45 ±5Hz
Low Frequency Recover 46 ±5Hz
High Frequency Alarm 65 ±5Hz
High Frequncy Recover 64 ±5Hz
Nominal Input Range 50Hz / 60Hz ±5Hz
AC Auto Restart YES
BATTERY
Minimum Start Voltage Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low Battery Voltage Alarm Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low Battery Voltage Cut Off 10-12.0VDC 20.0-24.0VDC
High Battery Voltage Alarm (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC)
AC CHARGE
Floating Voltage 13.5-14.5VDC 27-29VDC
Boost Voltage 13.8~14.5VDC 27.6~29VDC
Maximum Charge Current 300W 600W 800W 1000W 300W 600W 800W 1000W
10A 20A 25A 30A 5A 10A 15A 15A
BYPASS & PROTECTION
Input Waveform Pure sine wave
Input Frequency 50Hz or 60Hz
Overload Protection 110%~125% Load foult affter 60s; 125%~150% Load foult affter 3s; >150% Load fault after 500ms
Over Temperature Protection ≥90°C
Bypass Output Protection 10A 250VAC
Output Circuit Protection YES
Battery Reverse Protection Optional
Battery Low Voltage Protection YES
Battery High Voltage Protection YES
Bypass Breaker Rating 10A
Maximum Bypass Current 10A
MECHANICAL SPECIFICATION
Machine Dimension (W*H*D)(mm) 315*145*210
N.W(kg) 300W 600W 800W 1000W 300W 600W 800W 1000W
7.5 10.7 12.5 13.5 7.5 10.7 12.5 13.5
Package Dimension (W*H*D)(mm) 420*280*225
G.W(kg) 300W 600W 800W 1000W 300W 600W 800W 1000W
8 11.5 13 14.0 8 11.5 13 14
OTHER
Operating Temperature 0°C~40°C 0~90% relative humidity (non-condensing)
Storage Temperature -15°C to 55°C
Altitude ≤1000M
Audible Noise ≤60dB
Display LED+LCD
Cooling Mode Fan cooling
Fan Starting >45°C starting, <30°C Closing
Communication USB
CERTIFICATION & STANDARDS
CE-LVD (EN IEC62109-1:2010,EN IEC62109-2:2011)
CE-EMC+LVD (EN6100-6-4:2007, EN6100-6-2:2005+EN IEC62109-1:2010, EN IEC62109-2:2011)
IEC60950-1:2005A+1:2009+A2:2013 EN IEC62040-1:2019
]]> EP3000 LV2 Series (AC:120V 4-6KW) https://www.mustpower.com/product/ep3000-lv2-series-ac120v-4-6kw/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23920 Low Frequency Power Inverter/Charger 4~6KW | AC 120V | WIFI | BAT-CAN EP3000 LV2 series is very economical pure sine wave inverter, special in north & south america market, and AC charger from 35A to 70A .Solar/AC priority configurable . When solar priority , in case its charge current lower than inverter’s charger from AC , AC will supplement to charge the batteries, to optimize charging. With low frequency transformer ,it enable the inverter to operate with all kinds of home appliances.]]> ■ 3 Steps charging

■ MFD (multi-function display)

■ Overload and short-circuit protection

■ Set charging voltage/charging current.

■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5/12V

■ Power-save mode

■ Set utility priority/ Battery priority

■ Set utility input wide/narrow range

■ Inverter voltage can be set to 110V/115V/120V

■ Inverter frequency can be set to 50/60Hz

■ Set utility charging on/off switch

■ Acid or Lithium Select

■ WIFI monitoring function (optional)

■ With BMS lithium battery communication function (CAN port)

MODEL EP30-1012 LV2 EP30-1024 LV2 EP30-1512 LV2 EP30-1524 LV2 EP30-2012 LV2 EP30-2024 LV2 EP30-3024 LV2 EP30-3048 LV2 EP30-4024 LV2 EP30-4048 LV2 EP30-5048 LV2 EP30-6048 LV2
Nominal Battery System Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 24VDC 48VDC 24VDC 48VDC 48VDC 48VDC
INVERTER OUTPUT
Reted Power 1.0KW 1.5KW 2KW 3KW 4KW 5KW 6KW
Surge Rating 3000VA 4500VA 6000VA 9000VA 12000VA 15000VA 18000VA
Capable Of Starting Electric Motor 1HP 2HP 3HP
Waveform Pure sine wave/ same as input (bypass mode)
Nominal Output Voltage RMS 110V/115V/120VAC ±10% (RMS)
Output Frequency 50Hz / 60Hz±0.3 Hz
Inverter Efficiency(Peak) >88%
Line Mode Efficiency >95%
Power Factor 1.0
Typical Transfer Time 10ms(max)
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
AC INPUT
Voltage 120VAC
Selectable Voltage Range 75~135VAC(For Personal Computers)
Frequency Range 50Hz/60Hz (Auto sensing) 40~80Hz
BATTERY
Minimum Start Voltage (10V/ 10.5V/ 11V/ 11.5V/ 12V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low battery voltage alarm (10V/ 10.5V/ 11V/ 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low battery voltage cut off 10V/ 10.5V/ 11V/ 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High battery voltage alarm (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High battery voltage recover (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Energy saving mode Load ≤50±20W(120V)
CHARGER
Output Voltage Depends on battery type
Charger AC Input Breaker Rating 1K/30A 3K/40A 4-6KW/63A
Overcharge Protection S.D. 15.7VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode)
Maximum Charge Current 30A 20A 45A 25A 60A 30A 40A 20A 60A 30A 35A 40A
BYPASS & PROTECTION
Input Voltage Waveform Sine wave (grid or generator)
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load) Circuit breaker
Output Short Circuit Protection Circuit breaker
AC Input Breaker 30A 40A 50A / 63A
MECHANICAL SPECIFICATIONS
Mounting Wall Mount
Machine Dimension (W*H*D)(mm) 303*493*200 305*531*202
Package Dimension (W*H*D)(mm) 615*319*400 686*319*400
N.W(kg) /
G.W(kg) /
OTHER
Operation Temperature Range 0°C to 40°C
Storage Temperature -15°C to 60°C
Audible Noise 60dB MAX
Display LED+LCD
Standard Warranty 2 year
]]> EP3000 PLUS Series (1-3KW) https://www.mustpower.com/product/ep3000-plus-series-1-3kw/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23921 Low Frequency Power Inverter/Charger 1~3kW | 230V | WIFI EP3000 PLUS series is a very economical pure sine wave inverter, with AC charger from 20A to 60A; Solar/AC priority is configurable, when setting solar priority, solar will charge batteries as first priority, and AC can also charge batteries when solar charger current is too lower . With pure copper transformer, it enables inverter to operate with all kinds of home appliances.]]> ■ 3 Steps charging

■ Overload and short-circuit protection

■ Set charging voltage/charging current.

■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5V/ 12V

■ Power-save mode

■ Set utility priority/ Battery priority

■ Set utility input wide/narrow range

■ Inverter voltage can be set to 220V:220V/230V/240V

■ Inverter frequency can be set to 50/60Hz

■ Set utility charging on/off switch

■ Acid or Lituium select

■ WIFI remote monitoring (optional)

■ With BMS lithium battery communication function (CAN port)

MODEL EP30-1012 PLUS EP30-1024 PLUS EP30-1512 PLUS EP30-1524 PLUS EP30-2012 PLUS EP30-2024 PLUS EP30-3024 PLUS EP30-3048 PLUS EP30-4024 PLUS EP30-4048 PLUS EP30-5048 PLUS EP30-6048 PLUS
Nominal Battery System Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 24VDC 48VDC 24VDC 48VDC 48VDC 48VDC
INVERTER OUTPUT
Rated Power 1KW 1.5KW 2KW 3KW 4KW 5KW 6KW
Surge Rating 3000VA 4500VA 6000VA 9000VA 12000VA 15000VA 18000VA
Capable Of Starting Electric Motor 1HP 1HP 1HP 2HP 3HP
Waveform Pure sine wave / same as input (bypass mode)
Nominal Output Voltage RMS 220V / 230V / 240VAC ±10% (RMS)
Output Frequency 50Hz / 60Hz ±0.3Hz
Inverter Efficiency (Peak) >88%
Line Mode Efficiency >95%
Power Factor 1.0
Typical Transfer Time 10ms(max)
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 155~265VAC(For personal computers)
Frequency Range 50Hz / 60Hz(Auto sensing) 40~80Hz
BATTERY
Minimum Start Voltage (10V/ 10.5V/ 11V/ 11.5/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Alarm (10V/ 10.5V/ 11V/ 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Cut Off 10V/ 10.5V/ 11V/ 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Alarm (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Energy Saving Mode Load ≤100±20W(220V)
CHARGER
Output Voltage Depends on battery type
Charge AC Input Breaker Rating (230V) 1-3K/30A 4-6K/50A
Overcharge Protection S.D. 15.7VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode)
Maximum Charge Current 30A 20A 45A 25A 60A 30A 40A 20A 60A 30A 35A 40A
BYPASS & PROTECTION
Input Voltage Waveform Sine wave (grid or generator)
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load) Circuit breaker
Output Short Circuit Protection Circuit breaker
AC Input Breaker 1-3K/30A 4-6K/50A
MECHANICAL SPECIFICATIONS
Mounting Wall Mount
Machine Dimension (W*H*D)(mm) 303*493*200mm 305*531*202mm
Package Dimension (W*H*D)(mm) 615*400*319mm 686*400*319mm
N.W(kg) 14.8kg 15kg 18.8kg 17.1kg 19.5kg 18.6kg 20.3kg 20.1kg 31kg 29.5kg 30.9kg 34.5kg
G.W(kg) 16.3kg 16.5kg 20.3kg 18.6kg 21kg 20.1kg 21.8kg 21.6kg 32.5kg 31kg 32.4kg 36kg
OTHER
Operating Temperature Range 0°C to 40°C
Storage Temperature -15°C to 60°C
Audible Noise 60dB MAX
Display LED+LCD
Standard Warranty 1 year, 2 or 3 years optional (IP20)
CERTIFICATION & STANDARDS
CE-EMC+LVD(EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) IEC60950-1 A1+A2; CE-EMC+LVD,EN62040-2,EN62040-1
]]> EP3000 PLUS Series (4-6KW) https://www.mustpower.com/product/ep3000-plus-series-4-6kw/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23922 Low Frequency Power Inverter/Charger 4~6kW | 230V | WIFI EP3000 PLUS series is a very economical pure sine wave inverter, with AC charger from 20A to 60A; Solar/AC priority is configurable, when setting solar priority, solar will charge batteries as first priority, and AC can also charge batteries when solar charger current is too lower . With pure copper transformer, it enables inverter to operate with all kinds of home appliances.]]> ■ 3 Steps charging

■ Overload and short-circuit protection

■ Set charging voltage/charging current.

■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5V/ 12V

■ Power-save mode

■ Set utility priority/ Battery priority

■ Set utility input wide/narrow range

■ Inverter voltage can be set to 220V:220V/230V/240V

■ Inverter frequency can be set to 50/60Hz

■ Set utility charging on/off switch

■ Acid or Lituium select

■ WIFI remote monitoring (optional)

■ With BMS lithium battery communication function (CAN port)

MODEL EP30-1012 PLUS EP30-1024 PLUS EP30-1512 PLUS EP30-1524 PLUS EP30-2012 PLUS EP30-2024 PLUS EP30-3024 PLUS EP30-3048 PLUS EP30-4024 PLUS EP30-4048 PLUS EP30-5048 PLUS EP30-6048 PLUS
Nominal Battery System Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 24VDC 48VDC 24VDC 48VDC 48VDC 48VDC
INVERTER OUTPUT
Rated Power 1KW 1.5KW 2KW 3KW 4KW 5KW 6KW
Surge Rating 3000VA 4500VA 6000VA 9000VA 12000VA 15000VA 18000VA
Capable Of Starting Electric Motor 1HP 1HP 1HP 2HP 3HP
Waveform Pure sine wave / same as input (bypass mode)
Nominal Output Voltage RMS 220V / 230V / 240VAC ±10% (RMS)
Output Frequency 50Hz / 60Hz ±0.3Hz
Inverter Efficiency (Peak) >88%
Line Mode Efficiency >95%
Power Factor 1.0
Typical Transfer Time 10ms(max)
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 155~265VAC(For personal computers)
Frequency Range 50Hz / 60Hz(Auto sensing) 40~80Hz
BATTERY
Minimum Start Voltage (10V/ 10.5V/ 11V/ 11.5/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Alarm (10V/ 10.5V/ 11V/ 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Cut Off 10V/ 10.5V/ 11V/ 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Alarm (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Energy Saving Mode Load ≤100±20W(220V)
CHARGER
Output Voltage Depends on battery type
Charge AC Input Breaker Rating (230V) 1-3K/30A 4-6K/50A
Overcharge Protection S.D. 15.7VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode)
Maximum Charge Current 30A 20A 45A 25A 60A 30A 40A 20A 60A 30A 35A 40A
BYPASS & PROTECTION
Input Voltage Waveform Sine wave (grid or generator)
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load) Circuit breaker
Output Short Circuit Protection Circuit breaker
AC Input Breaker 1-3K/30A 4-6K/50A
MECHANICAL SPECIFICATIONS
Mounting Wall Mount
Machine Dimension (W*H*D)(mm) 303*493*200mm 305*531*202mm
Package Dimension (W*H*D)(mm) 615*400*319mm 686*400*319mm
N.W(kg) 14.8kg 15kg 18.8kg 17.1kg 19.5kg 18.6kg 20.3kg 20.1kg 31kg 29.5kg 30.9kg 34.5kg
G.W(kg) 16.3kg 16.5kg 20.3kg 18.6kg 21kg 20.1kg 21.8kg 21.6kg 32.5kg 31kg 32.4kg 36kg
OTHER
Operating Temperature Range 0°C to 40°C
Storage Temperature -15°C to 60°C
Audible Noise 60dB MAX
Display LED+LCD
Standard Warranty 1 year, 2 or 3 years optional (IP20)
CERTIFICATION & STANDARDS
CE-EMC+LVD(EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) IEC60950-1 A1+A2; CE-EMC+LVD,EN62040-2,EN62040-1
]]> EP3300 TLV Series (AC:110/220V 1-3KW) https://www.mustpower.com/product/ep3300-tlv-series-ac110-220v-1-3kw/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23923 Low Frequency Pure Sine Wave Split Phase Inverter Charger 1~3KW | AC110V/220V | MPPT 80A | WiFi | BAT-CAN This split phase inverter EP3300 TLV series, capacity from 1KW-3KW, DC 12V/24V/48V, it’s applicable to 110VAC/120VAC markets demands, which matches AC 110VAC/120V single phase, or two phase 220V/240V; In LCD display, you can set output voltage, frequency, charging voltage, charging current to design best use based on different loads applications; meanwhile, you can also connect extra solar charge controller to build a solar home system, take use of sunshine freely and save electricity bills.
Model Certification & Standards
EP33-1012/1024/1512/1524/2012/2024/3024/3048 TLV CE-EMC+LVD(EN6100-6-3: 2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> ■ Pure sine wave output
■ 3 steps charging
■ Overlord and short- circuit protection
■ Set charging voltage/charging current
■ Power-save mode
■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5/12V
■ Inverter voltage can be set to 100/110/120V
■ Inverter frequency can be set to 50/60Hz
■ Acid or Lithium select
■ WIFI monitoring function (optional)
■ With BMS lithium battery communication function (CAN port)

MODEL EP33-1012 TLV EP33-1024 TLV EP33-1512 TLV EP33-1524 TLV EP33-2012 TLV EP33-2024 TLV EP33-3024 TLV EP33-3048 TLV
INVERTER OUTPUT
Rated power 1KW 1.5KW 2KW 3KW
Surge rating 3000VA 4500VA 6000VA 9000VA
Capable of starting electric motor 1P 1P 1.5P 1.5P
Power factor 1
Wave form Pure sine wave / Same as input wave form (bypass mode)
Output voltage RMS 100V / 110V / 120VAC (200V / 220V / 240VAC) ±10%
Output frequency 50Hz or 60Hz (±0.3Hz) (can be set)
Overload protection Breaker + software protection
Output short circuit Breaker + software protection
Inverter efficiency (peak) >85%
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
BATTERY
Battery voltage 12VDC / 24VDC 24VDC / 48VDC
Minimum start voltage (10V/ 10.5V/ 11V/ 11.5V/ 12V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low battery voltage cut off 10V/ 10.5V/ 11V/ 11.5V/ 12V  for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low battery voltage alarm (10V/ 10.5V/ 11V/ 11.5V/ 12V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High battery voltage alarm (12-14.5V)+1V for 12VDC mode  (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover (12-14.5V)+0.5V  for 12VDC mode  (*2 for 24VDC, *4 for 48VDC)
Save mode Load ≤50±20W(120V)/100±20W(220V)
AC INPUT MODE
Input waveform Pure sine wave
Nominal input voltage 200Vac / 220Vac / 240Vac
Max input voltage 270Vac MAX
Input frequency 50Hz / 60Hz (auto sensing)
Efficiency (AC mode) >95% (load, full battery)
Transfer time AC to DC 15ms(max)
Transfer time DC to AC 15ms(max)
CHARGE MODE
Boost voltage 14.1V(Default) Range of adjustment 12-14.5V / *2 for 24VDC / *4 for 48VDC (Regulation step 0.1V)
Float voltage 13.5V(Default) Range of adjustment 12-14.5V / *2 for 24VDC / *4 for 48VDC (Regulation step 0.1V)
12V 30A 45A 60A /
24V 20A 25A 30A 40A
48V / / / 20A
Min charge current 10A. Change by every 5A
DIMENSIONS
Machine Dimension (W*H*D) 443*359.2*188mm
Package Dimension (W*H*D) 598*457*308mm
Warranty 1 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2)
]]>
