■ Output power factor 1
■ Built-in two 80A MPPT solar charge controllers
■ WIFI remote monitoring (optional)
■ Acid or Lithium Battery Select
■ CAN/RS485 communication for BMS
■ Compatible to generator

MODEL PH18-6048 TLV
Nominal Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 6000W
Surge Power 12000VA
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 120VAC/240VAC (L1/L2)
Inverter Efficiency(Peak) 90%~93%
Transfer Time 10ms (UPS / UL) 20ms (APL)
AC INPUT
Voltage 240VAC (L1/L2/N)
Selectable Voltage Range 214~264VAC(UL)
Frequency Range 50Hz / 60Hz(Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 250V
Maximum Solar Charge Current 80A/80A
PV Array MPPT Voltage Range 60~200VDC
PV Input Power 4000W/4000W
Maximum Efficiency 98%
Maximum AC Charge Current 60A/60A
Maximum Charge Current 280A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 318*560*249
Package Dimension (W*H*D)(mm) 678*345*420
N.W(kg) 21.5
G.W(kg) 24
OTHER
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature -10°C~50°C
Storage Temperature -15°C~60°C
Standard Warranty 2years
CERTIFICATION & STANDARDS
CE-LVD (IEC62109-1, EN IEC62109-2); UKCA-(BS EN 62109-1, BS EN 62109-2)
]]> PH1100 US Series (Split Phase 5-10KW) https://www.mustpower.com/product/ph1100-us-series-split-phase-5-10kw/ Wed, 26 Jun 2024 03:54:36 +0000 https://www.mustpower.com/?post_type=product&p=24459 Split Phase Hybrid Solar Inverter | AC 240/120V | DC 48V | PV 370V PH1100 US is brand new split phase hybrid inverter with low battery voltage 48V, ensuring system safe and reliable. With compact design and highpower density, this series supports 1.3 DC/AC ratio, saving device investment. It’s applicable to 110VAC/120VAC markets demands, which matches AC 110VAC/120V single phase, or two phase 220V/240V; Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remotely control, x1 DRM port, which makes the system smart and flexible.]]> ■ 100% unbalanced output, each phase max. output up to 50% rated power
■ Max. 6 pcs parallel for on-grid and off-grid operation
■ AC couple to retrofifit existing solar system
■ Support multiple batteries parallel
■ Max. charging/discharging current of 220A
■ Support storing energy from diesel generator
■ 48V low voltage battery, transformer isolation design
■ IP66 water-proof and dust-proof
■ “Time of use” function: a maximum of 6 time segments can be set
■ Wifi monitoring

MODEL PH11-5KL2-US PH11-6KL2-US PH11-8KL2-US PH11-10KL2-US
Rated power 5000W 6000W 8000W 10000W
BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~64V
Charging curve 3-stage adaptive with maintenance/Equalization
Charging Strategy for Li-lon Battery Self-adaption to BMS
Over-current protection/ Over-temperature protection Yes / Yes
Maximum charging/discharging power 5000W 6000W 8000W 10000W
Maximum charging/discharging current 110A 130A 170A 220A
PV STRING INPUT DATA
Max. DC Input Power 6500W 7800W 10400W 13000W
Maximum DC voltage 600V
Start-up Voltage 125V
Full Load DC Voltage Range 150~500V
Rated PV Input Voltage 370V
Minimum voltage for grid connection 150V
Enter high voltage error recovery point 600V
Maximum input current 16A/16A 16A/16A 32A/16A 32A/16A
No.of MPP Trackers 2 2 2 2
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/ Output Power 5000W 6000W 8000W 10000W
Max AC Input/ Output Power 5000W 6000W 8000W 10000W
AC Input/ Output Rated Current 20.8A/19.2A 25A/23A 33.3A/30.7A 41.6A/38.4A
Rated Input/Output Voltage/Range 120V/240V:208V
Rated Input/Output Grid Frequency/Range 60Hz±5Hz/ 50Hz±5Hz
Rated output power factor 1
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi) <3%
Grid Type Split Phase
DC Current Injection <0.5%
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
MPPT Efficiency 99.5%
PROTECTION
Integrated Islanding protection, Output overcurrent protection, Output overvoltage protection, PV input polarity reverse protection, DC Switch (optional), Ground Fault Sensing, leakage current monitoringprotection
Surge Protection DC Type III/AC Type III
Overvoltage Category DC Type II/AC Type III
GENERAL DATA
Operating Temperature Range (°C) -25°C~+60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤50dB
Altitude 3000m, >3000mDerating
Topology Battery-side transformer isolation, PV-side non-transformer isolation
Communication USB/ WiFi/ Enternet(optional)
Display 4.3-inch touch screen
Protection Degree IP66
Installation Style Wall-mounted
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
Package Dimension (W*H*D)(mm) 816*404*567
N.W(kg) 38
G.W(kg) 42
Warranty 5 Year
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
CERTIFICATION & STANDARDS
NBT32004-2013
]]> EP1800 LV Series (3KW) https://www.mustpower.com/product/ep1800-lv-series-3kw/ Fri, 24 May 2024 07:06:25 +0000 https://www.mustpower.com/?post_type=product&p=24287 High Frequency Power Inverter/Charger DC 24V | AC 120V This is a multi-function inverter/charger, combining functions of inverter, battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC charger priority, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter
■ Configurable input voltage range for home appliances and personal computers via LCD setting
■ Configurable battery charging current based on applications via LCD setting
■ Configurable AC Charger via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/ Over temperature/ short circuit protection
■ Smart battery charger design for optimized battery performance
■ Acid or Lithium select
■ Parallel operation with up to 3 units
■ WIFI remote monitoring (optional)
■ With BMS lithium battery communication function (CAN port)

MODEL EP18-3024LV
Rated output power 3000VA/3000W
Surge Power 6000W
AC INPUT
Nominal Input Voltage 120Vac±5%
Selectable Voltage range 90~145VAC(UPS) / 74~145VAC(APL) / 108~132VAC(UL)
Frequency Range 50Hz/60Hz (Auto sensing)
Inverter Efficiency(Peak) 95%
INVERTER OUTPUT
Output voltage waveform Pure sine wave
Output Voltage Regulation 120Vac ± 5%
Output Frequency 50Hz / 60Hz(Auto sensing)
Power Factor ≈1
Transfer Time 10ms (UPS / UL) / 20ms (APL) <50ms(For parallel operation)
Nominal DC Input Voltage 24VDC
Cold Start Voltage 23VDC
Output Short Circuit Protection Line mode Circuit Breaker
Battery mode Electronic Circuits
BATTERY
Battery voltage 24VDC
Floating voltage 27.4V
Overcharge Protection 30V
CHARGER
Charging Current(UPS) @Nominal Input Voltage Default:30A; MAX:80A
Bulk Charging Voltage 28.8Vdc
Floating Charging Voltage 27.4Vdc
Charging Algorithm 3-Step
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 297.5*468*125
Package Dimension (W*H*D)(mm) /
N.W(kg) /
G.W(kg) /
GENERAL
Mounting Wall mount
Display LED+LCD
Parallel operation 3 units
Operation Temperature Range -10°C to 50°C
Storage Temperature -15°C to 60°C
Standard Warranty 2 years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-4,EN6100-6-2+EN IEC62109-1)
]]> PH1100 LV Series (AC120V: 3.6/4KW) https://www.mustpower.com/product/ph1100-lv-series-ac120v-3-6-4kw/ Wed, 24 Apr 2024 03:31:31 +0000 https://www.mustpower.com/?post_type=product&p=24152 High Frequency On/Off Hybrid Solar Inverter 3.6/4KW | AC 120V | PV 500V | IP65 This is a flexible and intelligent energy storage solar inverter with a wide range of MPPT Voltage. Combining functions of off grid and on grid. This hybrid solar inverter can power all kinds of appliances in home or office, and can also be used in power stations.]]> ■ Multiple operation modes: Grid-tie,off grid with storage backup
■ IP65 water-proof and dust-proof
■ MPPT voltage range 120-500V
■ Support LCD display&Smart LCD setting
■ Available Export control CT sensor function
■ Multiple communications:USB,RS485,GPRS and wifi etc
■ Full protection function:Over-voltage,over-frequency, over-current, over-temperature,and AC short-circuit automatic protection
■ Intelligent BMS battery management function
■ Fanless low-noise design
■ Wifi monitoring

MODEL PH11-3648 LV PH11-4048 LV
Rated Power 3600W 4000W
Nominal Battery System Voltage 48V
PV INPUT(DC)
Maximum recommended DC power 4600W 5200W
Nominal DC operating voltage 360V
Maximum DC voltage 500V
MPPT voltage range 120V~500V
Maximum input current 15A / 15A
No.of MPP tracker 2
Strings per MPP tracker 1
INVERTER INPUT/ OUTPUT(AC)
Nominal AC input/ output power 3600W 4000W
Nominal input/ output voltage; range 110/120/130V; 90~140V
AC grid frequency; range 50/60Hz; 45~55/55-65Hz
Nominal input/ output current 30A 34A
Maximum input/ output current 33A 36A
Inrush current (spike/duration) 72A/5.2us
Total harmonic distortion i(THDi) <3%
Power factor at rated power 1
Displacement power factor 0.8leading ～ 0.8lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 3600W 4000W
Nominal output voltage; accuracy range 120±1%
Output ferequency; accuracy range 50/60Hz (optional)±0.2%
Output rated current 30A 34A
Output waveform Pure sine wave
Peak power 5400W,10s 6000W,10s
Total harmonic distortion v (linear load) <3%
BATTERY & CHARGER
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~60V
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 3600W 4000W
Maximum charging currernt 75A 85A
EFFICIENCY
Maximum efficiency 97.1%
Euro-efficiency 96.5%
MPPT efficiency 99.8%
PROTECTION DEVICES
DC switch rating for each MPPT; Grid monitoring; Output over current protection; Output overvoltage protection-varistor; Ground fault monitoring; Integrated all-pole sensitive leakage current
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 420*480*215
Package Dimension (W*H*D)(mm) 610*324*595
N.W(kg) 30
G.W(kg) 32
GENERAL
DC connection H4 / MC4
AC connection Terminal Block
Display LED+LCD
Communication interfaces Wi-Fi / USB / GPRS / RS485
Ingress protection rating IP65
Humidity 0~95% RH(No codensing)
Operating temperature range -20°C+60°C With derating above 45°C
Cooling concept Natural
Altitude <3000m
Standard Warranty 5years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3: 2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011); CE-LVD(EN62477-1:2022) IEC60529; EN50549-1:2019; Poland Type A, (NC RfG:2016, PSE:2018, PTPiREE:2021), C10/C11; UNE217001-2020; UNE217002-2020, NTS-631:2021 (Type A); G98+G99
]]> PV2900 LHP Series (AC:110V 1-6KW) https://www.mustpower.com/product/pv2900-lhp-series-ac110v-1-6kw/ Tue, 23 Apr 2024 11:35:14 +0000 https://www.mustpower.com/?post_type=product&p=24140 Low Frequency Solar Inverter AC 120V | MPPT 80A | WIFI | BMS | Dual output PV2900 LHP series is very economical pure sine wave solar inverter, AC voltage 110V/120V, AC charger inbuilt, from 20A to 60A; MPPT solar charger 80A inbuilt; Solar/AC priority is configurable, when setting solar priority, solar will charge batteries as first priority, and AC can also charge batteries when solar charger current is not enough, it enables inverter to operate with all kinds of home appliances, widely selling to Latin America.]]> ■ Pure sine wave output
■ 3 Steps charging
■ Overload and short-circuit protection
■ Set charging voltage/charging current.
■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5/12V
■ Power-save mode
■ Set utility priority/ Battery priority
■ Set utility input wide/narrow range
■ Inverter voltage can be set to 120V:110V/115V/120V
■ Inverter frequency can be set to 50/60Hz
■ Set utility charging on/off switch
■ 80A MPPT charger
■ Acid or Lithium Select
■ WiFi port (optional)
■ With BMS lithium battery communication function (CAN port)
■ Dual output for smart load management

MODEL PV29-1KW-LHP PV29-1.5KW-LHP PV29-2KW-LHP PV29-3KW-LHP PV29-4KW-LHP PV29-5KW-LHP PV29-6KW-LHP
Nominal Battery System Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 24VDC 48VDC 24VDC 48VDC 48VDC 48VDC
INVERTER OUTPUT
Rated Power 1 KW 1.5 KW 2 KW 3 KW 4 KW 5 KW 6 KW
Surge Rating 3000VA 4500VA 6000VA 9000VA 12000VA 15000VA 18000VA
Capable Of Starting Electric Motor 1P 1P 1.5P 2P 3P
Waveform Pure sine wave / same as input (bypass mode)
Nominal Output Voltage RMS 110V / 115V / 120VAC(±10% RMS)
Output Frequency 50Hz / 60Hz ±0.3Hz
Inverter Efficiency (Peak) >88%
Line Mode Efficiency >95%
Power Factor 1.0
Typical Transfer Time 10ms(max)
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
AC INPUT
Voltage 110/120VAC
Selectable Voltage Range 75~135VAC (For personal computers)
Frequency Range 50Hz / 60Hz(Auto sensing) 40~80Hz
BATTERY
Minimum Start Voltage (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Alarm (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Cut Off 10V / 10.5V / 11V / 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Voltage Alarm (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Idie Consumption-Search Mode Load ≤50±20W(120V)/100±20W(220V)
CHARGER
Output Voltage Depends on battery type
Overcharge Protection S.D. 15.5VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode)
Maximum Charge Current 30A 20A 45A 25A 60A 30A 40A 20A 60A 30A 35A 40A
PAYPASS & PROTECTION
Input Voltage Waveform Sine wave (grid or generator)
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load) Circuit breaker
Output Short Circuit Protection Circuit breaker
AC Input Breaker 1-3K/40A 4-6K/63A
SOLAR CHARGER
Maximum PV Array Power 1250W 2500W 1250W 2500W 1250W 2500W 2500W 5000W 2500W 5000W 5000W 5000W
Maximum PV Charge Current 80A±4A
DC Voltage 12V/ 24V auto work 24V/ 48V auto work
MPPT Range @ Operating Voltage 15~95VDC @ 12V/ 30~230VDC @ 24V 30~230VDC @ 24V/ 60~230VDC @ 48V
Maximum PV Array Open Circuit Voltage 245VDC
Standby Power Consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall Mount
Machine Dimension (W*H*D)(mm) 274*484*174 274*568.5*174
Package Dimension (W*H*D)(mm) 583.5*255*376 668.5*255*376
N.W(kg) / /
G.W(kg) / /
OTHER
Operating Temperature Range 0°C to 40°C
Storage Temperature -15°C to 60°C
Audible Noise 60dB MAX
Display LED+LCD
Standard Warranty 2 years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> EH2900 LV Series (AC:110V 300-1000W) https://www.mustpower.com/product/eh2900-lv-series-ac110v-300-1000w/ Tue, 23 Apr 2024 11:16:54 +0000 https://www.mustpower.com/?post_type=product&p=24134 Off Grid Inverter Charger 12V/24V | 10~30A | AC 120V EH2900 LV series inverter is a cost effective, intelligent with UPS function. The comprehensive LCD offers user-configurable and easy-accessible button adjustment such as battery charge current, battery charge voltage, frequency, buzzer etc. It's perfect for the user who need a simple and economical inverter,with user-friendly installnation and setting.]]> ■ Sine wave inverter
■ Adjustable charging current from utility
■ Adjustable battery charging current
■ 3 steps charging algorithm
■ Friendly user interface
■ Multi-function display
■ Overload and short-circuit protection
■ Battery reverse polarity protection
■ Deep discharge protection
■ Automatic voltage regulationCommunication with PC

MODEL EH29-0312 LV EH29-0412 LV EH29-0512 LV EH29-0612 LV EH29-0812 LV EH29-1012 LV EH29-0624 LV EH29-0824 LV EH29-1024 LV
Default Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated Power 300W 400W 500W 600W 800W 1000W 600W 800W 1000W
Surge Rating 900VA 1200VA 1500VA 1800VA 2400VA 3000VA 1800VA 2400VA 3000VA
Waveform Pure sine wave
Voltage Regulation Battery mode: 110 or 120VAC Line mode: 95~125VAC
Output Frequency 50Hz / 60Hz
Inverter Frequency (Peak) >75% >81%
Bypass Efficiency >95%
Output Transfer Time 8ms(typical) 12ms(max)
AC INPUT
Voltage 110/120VAC
Selectable Voltage Range 70~140VAC ±5%
Low battery voltage alarm 70VAC ±5%
Low battery voltage recover 75VAC ±5%
High battery voltage alarm 140VAC ±5%
High battery voltage recover 135VAC ±5%
Low Frequency Alarm 45 ±5Hz
Low Frequency Recover 46 ±5Hz
High Frequency Alarm 65 ±5Hz
High Frequncy Recover 64 ±5Hz
Nominal Input Range 50Hz / 60Hz ±5Hz
AC Auto Restart YES
BATTERY
Minimum start voltage Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low battery voltage alarm Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low battery voltage cutoff 10-12.0VDC 20.0-24.0VDC
High battery voltage alarm (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC)
AC CHARGE
Floating Voltage 13.5-14.5VDC 27-29VDC
Boost Voltage 13.8~14.5VDC 27.6~29VDC
Maximum Charge Current 300W 400W 500W 600W 800W 1000W 600W 800W 1000W
10A 10A 15A 20A 25A 30A 10A 15A 15A
BYPASS & PROTECTION
Input Waveform Pure sine wave
Input Frequency 50Hz or 60Hz
Overload Protection >110%~125% Load fault after 60s; >125%~150% Load fault after 3s; >150% Load fault after 500ms
Over Temperature Protection ≥90°C
Bypass Output Protection 15A 250VAC
Output Circuit Protection YES
Battery Reverse Protection Optional
Battery Low Voltage Protection YES
Battery High Voltage Protection YES
Bypass Breaker Rating 15A
Maximum Bypass Current 15A
MECHANICAL SPECIFICATION
Machine Dimension (W*H*D)(mm) 300.5*319*132.2
Package Dimension (W*H*D)(mm) 391*187*325
N.W(kg) /
G.W(kg) /
GENERAL
Operating Temperature 0°C~40°C 0~90% relative humidity (non-condensing)
Storage Temperature -15°C to 55°C
Altitude ≤1000M
Audible Noise ≤60dB
Display LED+LCD
Cooling Mode Fan cooling
Fan Starting >45°Cstarting, <30°C Closing
Communication USB
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-LVD (EN IEC62109-1:2010,EN IEC62109-2:2011);CE-EMC+LVD (EN6100-6-4:2007, EN6100-6-2:2005+EN IEC62109-1:2010, EN IEC62109-2:2011) IEC60950-1:2005A+1:2009+A2:2013; EN IEC62040-1:2019
]]> PV3900 TLV Series (AC:110/220V 8-12KW) https://www.mustpower.com/product/pv3900-tlv-series-ac110-220v-8-12kw/ Wed, 06 Mar 2024 11:29:57 +0000 https://www.mustpower.com/?post_type=product&p=23970 Low Frequency Solar Inverter PV 250V | MPPT 200A |DC 48V PV3900 TLV series is a multi-function inverter ,combining functions of inverter and MPPT solar charger controller, solar charger and battery charger to offer uninterruptible power support. The comprehensive LCD display offers userconfigurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and selectable input voltage based on different applications.]]> ■ Smart LCD setting(Working modes, Charge Current, Charge voltage, etc.)
■ Built-in MPPT solar charge controller 200A
■ MPPT efficiency max 98%
■ Powerful charge rate up to 200A
■ Inside BMS function
■ DC start &Automatic Self-Diagnostic Function
■ WIFI monitoring function (optional)
■ Compatible to generator
■ Parallel operation with up to 3 units

MODEL PV39-8048 TLV PV39-10048 TLV PV39-12048 TLV
Nominal Battery System Voltage 48VDC
Stand-alone mode Yes
Parallel operation 3 units
INVERTER OUTPUT
Rated power 8KW 10KW 12KW
Surge rating 24000VA 30000VA 36000VA
Capable of starting electric motor 4HP 5HP 6HP
Waveform Pure sine wave / same as input (bypass mode)
Nominal output voltage RMS 100V/110V/120V/200V/220V/240V
Inverter effciency(peak) >90%
Line mode efficiency >95%
Power factor 1.0
Typical transfer time 10ms(max)
AC INPUT
Voltage 220V/230V/240V
Selectable voltage range 90-280 VAC (APL)
Frequency range 50Hz / 60Hz
BATTERY
Low battery voltage cutoff 40-48VDC for 48VDC mode
Low battery voltage recover 42-50VDC for 48VDC mode
High battery voltage cutoff 60VDC for 48VDC mode
High battery voltage recover 57VDC for 48VDC mode
No-load loss <50W
AC CHARGER
Output voltage Depends on battery type (Supports lead-acid, gel, and lithium batteries)
Charger AC input breaker rating 100A
Overcharge protection S.D. 62.8VDC for 48VDC mode
Maximum charge current 10-140A (setting) battery terminal
BTS
Continuous output power Yes Variances in charging voltage & S.D. voltage base on the battery temperature
BYPASS & PROTECTION
Input voltage waveform Sine wave (grid or generator)
Nominal input frequency 50Hz or 60Hz
Overload protection (SMPS Load) Software + Circuit breaker
Output short circuit protection Software + Circuit breaker
Bypass breaker rating 63A
Max bypass current 80A
SOLAR CHARGER
Maximum PV charge current 200A
DC voltage 48V
Maximim PV array power 10000W 10000W 10000W
MPPT range @ operating voltage(VDC) 64~235VDC
Maximum PV array open circuit voltage 250VDC
Maximum effciency >98%
Standby power consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall mount
Packing Wooden box
Machine Dimension (W*H*D)(mm) 439*660.5*233.2
Package Dimension (W*H*D)(mm) 782*314.5*520.5
N.W(kg) 55 62 69
G.W(kg) 73 80 87
OTHER
Operation temperature range 0°C to 50°C
Storage temperature 15°C to 60°C
Audible noise 60dB MAX
Communication WiFi
Display LED+LCD
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011); UL1741
]]> PH1600 LV Series (AC120V: 3-4KW) https://www.mustpower.com/product/ph1600-lv-series-ac120v-3-4kw/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23951 AC Coupled Battery Storage Inverter 3~4KW | Single Phase | 120VAC The PH1600 LV Series is designed for retrofitting PV systems, including power classes ranging from 3kw to 4kw. It can be installed with existing PV inverters, forming an AC coupling system. Capable of being grid-interactive, it allows users to store surplus power and sell it back to the grid when demand peaks and the price of electricity is at its highest. It runs reliably under even the most extreme conditions with metal aluminium housing with IP66 protection.]]> ■ LCD+LED – user friendly interface

■ IP66 design for outdoor

■ Compatible with other brands of inverter

■ Various work mode for different application scenarios

■ Natural cooling without external fan

■ BMS Function

■ Wifi monitoring

■ UPS level switching time <10 ms ■ Retrofit any on-grid systems to be able to run battery

MODEL PH16-3048 LV PH16-3548 LV PH16-4048 LV
Rated Power 3000W 3500W 4000W
Nominal Battery System Voltage 48V 48V 48V
INVERTER OUTPUT(AC)
Nominal AC output power 3000W 3500W 4000W
Nominal output voltage range 110/120,90~140 ±5VAC
AC grid frequency range 60Hz; 55-65Hz
Nominal output current 25A 29.1A 33.3A
Maximum output current 36.36A
Inrush current (spike/duration) 57.5A/5.2us
Total harmonic distortion i(THDi) @Nominal Output <3%
Power factor at rated power ≈1
Displacement power factor Adjustable from 0. 8 leading to 0. 8 lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 3000W 3500W 4000W
Nominal output voltage; accuracy range 120±1%
Output ferequency; accuracy range 60Hz±0.2%
Output rated current 25A 29.1A 33.3A
Output waveform Pure sine wave
Peak power 3000VA, 10S 3500VA, 10S 4000VA, 10S
Total harmonic distortion v (linear load) <3%
BATTERY & CHARGER
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V ±0.3
Battery voltage range 40~60V ±0.3
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 3000W 3500W 4000W
Maximum charging currernt 80A
EFFICIENCY
Battery discharge (full load) ≥92%
Maximum battery charging current efficiency ≥92%
PROTECTION DEVICES
Grid monitoring Yes
Output over current protection Yes
Output overvoltage protection-varistor Yes
Ground fault monitoring Yes
Integrated all-pole sensitive leakage current Yes
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 420*420*215
Package Dimension (W*H*D)(mm) /
N.W(kg) 25
G.W(kg) /
GENERAL
AC connection Terminal Block
Display LED+LCD
Communication interfaces Wi-Fi/USB/GPRS/RS485/CAN
Ingress protection rating IP66
Humidity 0~95% RH(No codensing)
Operating temperature range -20°C+60°C With derating above 45°C
Cooling concept Natural
Noise figure [dB] ≤25
Altitude <3000m
Standard Warranty 5years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN IEC61000-6-3, ENIEC61000-6-1; EN IEC62477-1)
]]> PI1500 LV Series (AC:120V 300W) https://www.mustpower.com/product/pi1500-lv-series-ac120v-300w/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23953 Pure Sine Wave Power Inverter 300W | DC 12V,24V | AC 120V PI1500 series is a pure sine wave inverter, high frequency machine solution, the product is small size, the solution is reliable and stable, the main function is to invert the DC 12VDC battery or 24VDC battery to AC 120VAC output, mainly used for emergency use Electricity, car inverter, outdoor electricity and other occasions.]]> ■ Input Voltage 12V / 24V DC optional

■ Output Voltage 120V AC optional

■ Portable power for AC products, AC outlets for connecting multiple loads

■ High efficiency converts virtually all of the battery’s power to AC

■ Mounting brackets for convenient installation

■ Overload and over temperature shut down

■ Low voltage and over voltage alarm/cut off

■ Short circuit protection

MODEL PI15-0312 LV PI15-0324 LV PI15-0612 LV PI15-0624 LV PI15-1012 LV PI15-1024 LV PI15-1512 LV PI15-1524 LV PI15-2012 LV PI15-2024 LV
BATTERY DC INPUT
Input Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC
Low Voltage Protect Delay 2 seconds
Low Voltage Warning (PB) 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC
(LI) 10.5VDC 21.0VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC
Low Voltage Protect (PB) 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC
(LI) 11.5VDC 23.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC
Low Voltage Restoring (PB) 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 23.0VDC 12.5VDC 23.0VDC
(LI) 12.5VDC 25.0VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC
Over Voltage Protect (PB) 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC
(LI) 14.7VDC 29.4VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC
Over Voltage Restoring (PB) 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC
(LI) 15.0VDC 30.0VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power 300W 600W 1000W 1500W 2000W
Peak Power 600W 1200W 2000W 3000W 4000W
Output AC Voltage 120V 120V 120V 120V 120V
Output AC Frequency 60Hz 60Hz 60Hz 60Hz 60Hz
Output Wave Pure Sine Wave
Output Wave THD < 3%
PROTECTION
Battery Input Protection Low Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output Protection Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED Display Red: Error ; Green: System OK
LED Digital Display / Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USB USB-A type (5V1A)
EFFICIENCY
Peak Conversion efficiency 91% 91% 90% 88% 90% 88% 90%
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 205*125*61 242*158*81 291*220*83 380.8*248*90
Package Dimension (W*H*D)(mm) 228*102*176 268*140*205 330*147*267 420*150*300
N.W(kg) 1 1.7 2.6 4.5
G.W(kg) 9.3 (8pcs) 15 (8pcs) 23 (8pcs) 19 (4pcs)
OTHER
Protection Degree IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
Working Environment Indoor Fan cooling
Environmental temperature 0~45°C
Ambient humidity 20%-90%, No condensation
Altitude ≤3000m
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) CE-LVD(EN 62477-1/A11)
]]> PI1500 LV Series (AC:120V 600W) https://www.mustpower.com/product/pi1500-lv-series-ac120v-600w/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23954 Pure Sine Wave Power Inverter 600W | DC 12V,24V | AC 120V PI1500 series is a pure sine wave inverter, high frequency machine solution, the product is small size, the solution is reliable and stable, the main function is to invert the DC 12VDC battery or 24VDC battery to AC 120VAC output, mainly used for emergency use Electricity, car inverter, outdoor electricity and other occasions.]]> ■ Input Voltage 12V / 24V DC optional

■ Output Voltage 120V AC optional

■ Portable power for AC products, AC outlets for connecting multiple loads

■ High efficiency converts virtually all of the battery’s power to AC

■ Mounting brackets for convenient installation

■ Overload and over temperature shut down

■ Low voltage and over voltage alarm/cut off

■ Short circuit protection

MODEL PI15-0312 LV PI15-0324 LV PI15-0612 LV PI15-0624 LV PI15-1012 LV PI15-1024 LV PI15-1512 LV PI15-1524 LV PI15-2012 LV PI15-2024 LV
BATTERY DC INPUT
Input Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC
Low Voltage Protect Delay 2 seconds
Low Voltage Warning (PB) 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC
(LI) 10.5VDC 21.0VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC
Low Voltage Protect (PB) 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC
(LI) 11.5VDC 23.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC
Low Voltage Restoring (PB) 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 23.0VDC 12.5VDC 23.0VDC
(LI) 12.5VDC 25.0VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC
Over Voltage Protect (PB) 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC
(LI) 14.7VDC 29.4VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC
Over Voltage Restoring (PB) 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC
(LI) 15.0VDC 30.0VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power 300W 600W 1000W 1500W 2000W
Peak Power 600W 1200W 2000W 3000W 4000W
Output AC Voltage 120V 120V 120V 120V 120V
Output AC Frequency 60Hz 60Hz 60Hz 60Hz 60Hz
Output Wave Pure Sine Wave
Output Wave THD < 3%
PROTECTION
Battery Input Protection Low Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output Protection Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED Display Red: Error ; Green: System OK
LED Digital Display / Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USB USB-A type (5V1A)
EFFICIENCY
Peak Conversion efficiency 91% 91% 90% 88% 90% 88% 90%
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 205*125*61 242*158*81 291*220*83 380.8*248*90
Package Dimension (W*H*D)(mm) 228*102*176 268*140*205 330*147*267 420*150*300
N.W(kg) 1 1.7 2.6 4.5
G.W(kg) 9.3 (8pcs) 15 (8pcs) 23 (8pcs) 19 (4pcs)
OTHER
Protection Degree IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
Working Environment Indoor Fan cooling
Environmental temperature 0~45°C
Ambient humidity 20%-90%, No condensation
Altitude ≤3000m
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) CE-LVD(EN 62477-1/A11)
]]>
