Dual output inverter – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Thu, 10 Apr 2025 08:21:07 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 PH1900 EXP Series (6-12kW) https://www.mustpower.com/product/ph1900-exp-series-6-12kw/ Wed, 04 Dec 2024 07:04:23 +0000 https://www.mustpower.com/?post_type=product&p=24822 Dual Output Hybrid Solar Inverter PH1900 EXP is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PH1900 EXP Series can run without battery. The Maximum PV input voltage can reach 500V and MPPT voltage range is 90~450Vdc, built-in two MPPTs solar charge controller, which can help customers make full use of solar energy.]]> ■ Dual output for smart load management
■ Smart color LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in Two MPPTs solar charge controller
■ Wide MPPT voltage range is 90~450V, the maximum PV input voltage can reach 500V (450V for parallel)
■ Can provide the power to the load without battery
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ With BMS lithium battery communication function
■ With AC/PV lithium battery activation function
■ Support USB, RS485 monitoring function
■ Parallel operation up to 6 units
■ WIFI remote monitoring

MODEL PH19-6248 EXP PH19-8048 EXP PH19-10048 EXP PH19-11048 EXP PH19-12048 EXP
Default Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 6200VA/6200W 8000VA/8000W 10000VA/10000W 11000VA/11000W 12000VA/12000W
Surge Power 12400W 16000W 20000W 22000W 24000W
Waveform Pure Sine Wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 92%
Transfer Time 10ms(UPS / VDE4105) / 20ms(APL)
AC INPUT
Voltage 230VAC
Max AC Input Voltage 300VAC
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 500VDC (450V for parallel)
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 4000W*2 4000W*2 5000W*2 6000W*2 6000W*2
Maximum PV Input Current 18A*2 18A*2 27A*2(40A max) 27A*2(40A max) 27A*2(40A max)
PV Array MPPT Voltage Range 90~450VDC (90~430VDC for parallel)
Min Battery Voltage For PV charge 34VDC
Maximum Solar Charge Current 120A 120A 150A 150A 150A
Maximum AC Charge Current 100A 120A 150A 150A 150A
Maximum Charge Current 120A 120A 150A 150A 150A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D) 425*473*145mm 425*527*145mm
Package Dimension (W*H*D) / / / / /
N.W (kg) / 17.4 17.4 / 17.6
G.W (kg) / / / / /
OTHER
Humidity 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature Range 0°C~50°C
Storage Temperature Range -15°C~60°C
Warranty 2 year
CERTIFICATION & STANDARDS
CE
]]> PV1800 PRO II Series (6.2-12kW) https://www.mustpower.com/product/pv1800-pro-ii-series-6-2-12kw/ Wed, 04 Dec 2024 06:56:16 +0000 https://www.mustpower.com/?post_type=product&p=24816 Dual Output Inverters PV1800 PRO II is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV1800 PRO II Series can run without battery. The Maximum PV input voltage can reach 500V and MPPT voltage range is 90~430Vdc, built-in two MPPTs solar charge controller, which can help customers make full use of solar energy.]]> ■ Dual output for smart load management
■ Smart color LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in Two MPPTs solar charge controller
■ Wide MPPT voltage range is 90~450V, the maximum PV input voltage can reach 500V
■ Can provide the power to the load without battery
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ With BMS lithium battery communication function
■ With AC/PV lithium battery activation function
■ Support USB, RS485 monitoring function
■ Parallel operation up to 6 units (optional)
■ WIFI remote monitoring (optional)

MODEL PV18-6248 PRO II PV18-8048 PRO II PV18-10048 PRO II PV18-11048 PRO II PV18-12048 PRO II
Default Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 6200VA/6200W 8000VA/8000W 10000VA/10000W 11000VA/11000W 12000VA/12000W
Surge Power 12400W 16000W 20000W 22000W 24000W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 92%
Transfer Time 10ms(UPS / VDE4105) / 20ms(APL)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 500VDC
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 4000W*2 4000W*2 5000W*2 6000W*2 6000W*2
Maximum PV Input Current 18A*2 18A*2 27A*2(40A max) 27A*2(40A max) 27A*2(40A max)
PV Array MPPT Voltage Range 90~430VDC
Maximum Solar Charge Current 120A 120A 150A 150A 150A
Maximum AC Charge Current 100A 120A 150A 150A 150A
Maximum Charge Current 120A 120A 150A 150A 150A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 425*473*145 425*527*145
Package Dimension (W*H*D)(mm) / / / / /
N.W (kg) / / / / /
G.W (kg) / / / / /
OTHER
Humidity 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature Range 0°C~50°C
Storage Temperature Range -15°C~60°C
Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2020+A11:2020
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2018, EN IEC62109-1:2010, EN IEC62109-2:2011
]]> PV1800 PRO II Series (4/6kW) https://www.mustpower.com/product/pv1800-pro-ii-series-4-6kw/ Wed, 04 Dec 2024 06:48:34 +0000 https://www.mustpower.com/?post_type=product&p=24811 Dual Output Solar Power Inverter PV1800 PRO II is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV1800 PRO II Series can run without battery. The Maximum PV array open circuit voltage can reach 500V and MPPT voltage range is 90~430V for 4KW, 120v~430V for 6KW, which Can help customers make full use of solar energy.]]> ■ Pure sine wave output
■ Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in MPPT solar charge controller
■ MAX PV Array Open Circuit Voltage: 500V (450V for parallel)
■ Can provide the power to the load without battery
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ Cold start function
■ Support USB, RS485 monitoring function
■ Parallel operation with up to 6 units (optional)
■ WIFI remote monitoring (optional)
■ Dual outputs for smart load management
■ Can communicate with lithium batteries

MODEL PV18-4024 PRO II PV18-6048 PRO II
Default Battery System Voltage 24VDC 48VDC
INVERTER OUTPUT
Rated Power 4000VA / 4000W 6000VA / 6000W
Surge Power 8000W 12000W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 92%
Transfer Time 10ms(UPS / VDE4105) / 20ms(APL)/ < 50ms typical (For parallel operation)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage 24VDC 48VDC
Floating Charge Voltage 27.4VDC 54.8VDC
Overcharge Protection 30VDC 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 500VDC (450V for parallel)
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 5000W 6000W
PV Array MPPT Voltage Range 90~430VDC 120~430 VDC
Maximum Solar Charge Current 100A 120A
Maximum AC Charge Current 80A 100A
Maximum Charge Current 100A 120A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 322*486*134 309*505*147
Package Dimension (W*H*D)(mm) 575*229*425 603*260*400
N.W (kg) 9.5 12.5
G.W (kg) 12 13.8
OTHER
Humidity 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature 0°C~50°C
Storage Temperature -15°C~60°C
Communication Interface USB/ WIFI
Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2020+A11:2020
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2018, EN IEC62109-1:2010, EN IEC62109-2:2011
]]> PV2900 HP Series (1-6KW) https://www.mustpower.com/product/pv2900-hp-series-1-6kw/ Wed, 24 Apr 2024 03:48:41 +0000 https://www.mustpower.com/?post_type=product&p=24155 Low Frequency Inverter 1~6KW | AC 230V | MPPT 80A | PV 245V PV2900 HP series is very economical pure sine wave solar inverter, Inbuilt with 80A MPPT charger; Solar/AC priority is configurable, when setting solar priority, solar will charge batteries as first priority, and AC can also charge batteries when solar charger current is too lower, in this way system charge is optimazed best. it enables inverter to operate with all kinds of home appliances.]]> ■ 3 Steps charging
■ Overload and short-circuit protection
■ Set charging voltage/charging current
■ Battery low voltage shutdown point can be set to 10/10.5/11/11.5/12V
■ Power-save mode
■ Set utility priority /battery priority
■ Set utility input wide/narrow voltage range
■ Inverter voltage can be set to 220V/230V/240V
■ Inverter frequency can be set to 50Hz/60Hz
■ Set utility charging on/off switch
■ Inbuilt 80A MPPT Solar Charge Controller
■ Acid or Lithium Select
■ WIFI remote monitoring (optional)
■ With BMS lithium battery communication function (CAN port)
■ Dual output for smart load management

MODEL PV29-1KW-HP PV29-1.5KW-HP PV29-2KW-HP PV29-3KW-HP PV29-4KW-HP PV29-5KW-HP PV29-6KW-HP
Nominal Battery System Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 24VDC 48VDC 24VDC 48VDC 48VDC 48VDC
INVERTER OUTPUT
Rated Power 1 KW 1.5 KW 2 KW 3 KW 4 KW 5 KW 6 KW
Surge Rating 3000VA 4500VA 6000VA 9000VA 12000VA 15000VA 18000VA
Capable Of Starting Electric Motor 1P 1P 1.5P 2P 3P
Waveform Pure sine wave / same as input (bypass mode)
Nominal Output Voltage RMS 220V / 230V / 240VAC (±10% RMS)
Output Frequency 50Hz / 60Hz ±0.3Hz
Inverter Efficiency (Peak) >88%
Line Mode Efficiency >95%
Power Factor 1.0
Typical Transfer Time 10ms(max)
Overload 100% < Load < 110% (alarm 5min then stop output and fault code 07) 110% < Load < 125% (alarm 60s then stop output and fault code 07) Load > 125% (alarm 10s then stop output and fault code 07)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 155~265VAC(For personal computers)
Frequency Range 50Hz / 60Hz(Auto sensing) 40~80Hz
BATTERY
Minimum Start Voltage (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Alarm (10V / 10.5V / 11V / 11.5V/ 12V )+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Low Battery Voltage Cut Off 10V / 10.5V / 11V / 11.5V/ 12V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Alarm (12-14.5V)+1V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
High Battery Voltage Recover (12-14.5V)+0.5V for 12VDC mode (*2 for 24VDC, *4 for 48VDC)
Energy Saving Mode Load ≤50±20W(120V)/100±20W(220V)
CHARGER
Output Voltage Depends on battery type
Overcharge Protection S.D. 15.5VDC for 12VDC mode (*2 for 24VDC mode, *4 for 48VDC mode)
Maximum Charge Current 30A 20A 45A 25A 60A 30A 40A 20A 60A 30A 35A 40A
PAYPASS & PROTECTION
Input Voltage Waveform Sine wave (grid or generator)
Nominal Input Frequency 50Hz or 60Hz
Overload Protection (SMPS Load) Circuit breaker
Output Short Circuit Protection Circuit breaker
AC Input Breaker 1-3K/30A 4-6K/50A
SOLAR CHARGER
Maximum PV Array Power 1250W 2500W 1250W 2500W 1250W 2500W 2500W 5000W 2500W 5000W 5000W 5000W
Maximum PV Charge Current 80A±4A
DC Voltage 12V/ 24V auto work 24V/ 48V auto work
MPPT Range @ Operating Voltage 15~95VDC @ 12V/ 30~230VDC @ 24V 30~230VDC @ 24V/ 60~230VDC @ 48V
Maximum PV Array Open Circuit Voltage 245VDC
Standby Power Consumption <2W
MECHANICAL SPECIFICATIONS
Mounting Wall Mount
Dimensions (W*H*D) 274*484*174mm 274*568.5*174mm
Package Dimensions (W*H*D) 583.5*376*255mm 668.5*376*255mm
N.W (kg) / /
G.W (kg) / /
OTHER
Operating Temperature Range 0°C ~ 40°C
Storage Temperature -15°C ~ 60°C
Audible Noise 60dB MAX
Display LED+LCD
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
]]> PV1800 ECO Series (1.6-6.2KW) https://www.mustpower.com/product/pv1800-eco-series-1-6-6-2kw/ Tue, 23 Apr 2024 11:41:38 +0000 https://www.mustpower.com/?post_type=product&p=24145 High Frequency Off Grid Solar Inverter 1.6~6.2KW | PV 400/450/500V | Dual output | DC 12V,24V,48V PV1800 ECO is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV1800 ECO Series can run without battery. The Maximum PV input voltage can reach 400V/450V/500V, which can help customers make full use of solar energy.]]> ■ Pure sine wave output
■ Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in MPPT solar charge controller
■ Wide PV input voltage range
■ Can provide the power to the load without battery
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ Cold start function
■ Support RS485,CAN monitoring function
■ Dual outputs for smart load management
■ Can communicate with lithium batteries (CAN port)

MODEL PV18-1612 ECO PV18-2524 ECO PV18-3024 ECO PV18-3524 ECO PV18-5548 ECO PV18-6248 ECO
Default Battery System Voltage 12VDC 24VDC 24VDC 24VDC 48VDC 48VDC
INVERTER OUTPUT
Rated Power 2000VA/1600W 2500VA/2500W 3000VA/3000W 3500VA/3500W 5500VA/5500W 6200VA/6200W
Output Channel Dual Dual Dual Dual Dual Dual
Surge Power 3200W 5000W 6000W 7000W 11000W 12400W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) >90%
Transfer Time Typical < 10ms , 20ms max
AC INPUT
Voltage 230VAC
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage 12V 24VDC 24VDC 24VDC 48VDC 48VDC
Floating Charge Voltage 13.7VDC 27.4VDC 27.4VDC 27.4VDC 54.8VDC 54.8VDC
Overcharge Protection 15VDC 30VDC 30VDC 30VDC 60VDC 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Input Voltage 400VDC 400VDC 400VDC 450VDC 450VDC 500VDC
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 2000W 4000W 4000W 4000W 6000W 6200W
PV Array MPPT Voltage Range(Typ.) 30~320VDC 30~320VDC 30~320VDC 60~360VDC 60~360VDC 120~450VDC
PV maximum input current 16A 18A 18A 18A 28A 28A
Maximum Solar Charge Current 80A 100A 100A 100A 100A 120A
Maximum AC Charge Current 80A 60A 60A 60A 100A 100A
Maximum Charge Current 80A 100A 100A 100A 100A 120A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 290*367*111 290*367*111 290*367*111 318*367*122.5 318*454*122.5 318*428*140
Package Dimension (W*H*D)(mm) 446*394*187 446*394*187 446*394*187 446*410*200 544.5*410*210 550*400*220
N.W (kg) 6.4 6.7 6.7 7.3 9.0 10.0
G.W (kg) 7.4 7.7 7.7 8.3 10.5 11.6
OTHER
Humidity 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature 0°C~50°C
Storage Temperature -15°C -60°C
Warranty 2years
CERTIFICATION & STANDARDS
CE
]]> PV1800 PREM Series (1.6-5.5KW) https://www.mustpower.com/product/pv1800-prem-series-1-6-5-5kw/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23938 High Frequency Off Grid Solar Inverter 1.6~5.5KW | PV 400/450V | Dual output | DC 12V,24V,48V PV1800 PREM is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV1800 PREM Series can run without battery. The Maximum PV array open circuit voltage can reach 400V/450V. which Can help customers make full use of solar energy.]]> ■ Pure sine wave output
■ Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in MPPT solar charge controller
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ Cold start function
■ Support USB, RS485, CAN monitoring function
■ WIFI remote monitoring (Built in wifi module and antenna)
■ PV/ AC activation function
■ BMS communication function (CAN Port)
■ Dual output for smart load management

MODEL PV18-1612 PREM PV18-2524 PREM PV18-3024 PREM PV18-3524 PREM PV18-5548 PREM
Nominal Battery System Voltage 12VDC 24VDC 24VDC 24VDC 48VDC
INVERTER OUTPUT
Rated Power (Main+Second Load) 2000VA/1600W 2500VA/2500W 3000VA/3000W 3500VA/3500W 5500VA/5500W
Surge Power 3200W 5000W 6000W 7000W 11000W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 90~93%
Transfer Time 10ms (UPS / VDE4105) / 20ms (APL)
AC INPUT
Voltage 230VAC±5%
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105)
Frequency Range 50Hz / 60Hz(Auto sensing)
BATTERY
Normal voltage 12VDC 24VDC 24VDC 24VDC 48VDC
Floating Charge Voltage 13.7VDC 27.4VDC 27.4VDC 27.4VDC 54.8VDC
Overcharge Protection 15VDC 30VDC 30VDC 30VDC 60VDC
SOLAR CHARGER &AC CHARGER
Maximum PV Array Open Circuit Voltage 400VDC 400VDC 400VDC 450VDC 450VDC
Maximum PV Input Current 16A 18A 18A 18A 28A
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 2000W 4000W 4000W 4000W 6000W
PV Array MPPT Voltage Range(Typ.) 30~320VDC 60~360VDC
Maximum Solar Charge Current 80A 100A
Maximum AC Charge Current 80A 60A 60A 60A 100A
Maximum Charge Current 80A 100A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 290*367*111 290*367*111 290*367*111 318*367*122.5 318*454*122.5
Package Dimension (W*H*D)(mm) 446*394*187 446*394*187 446*394*187 459*410*200 544.5*410*200
N.W (kg) 6.4 6.6 6.6 7.2 9.0
G.W (kg) 7.4 7.6 7.6 8.2 10.5
OTHER
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature 0°C~50°C
Storage Temperature -15°C~60°C
Warranty 2years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2)
]]> PV1900 EXP Series (4/6KW) https://www.mustpower.com/product/pv1900-exp-series-4-6kw/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23939 High Frequency solar Inverter 4~6KW | PV 500V | MPPT 100A/120A | DC 24V,48V PV1900 EXP is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV1900 EXP Series can run without battery. The Maximum PV array open circuit voltage can reach 500V and MPPT voltage is 150~450Vdc, which Can help customers make full use of solar energy.]]> ■ Pure sine wave output
■ Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in MPPT solar charge controller
■ MAX PV Array Open Circuit Voltage: 500V (450V for parallel)
■ Can provide the power to the load without battery
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ Cold start function
■ Support USB, RS485 monitoring function
■ Parallel operation with up to 9 units (for 48V mode)
■ WIFI remote monitoring (optional)
■ Dual outputs for smart load management(optional)
■ Can communicate with lithium batteries

MODEL PV19-4024 EXP PV19-6048 EXP
Default Battery System Voltage 24VDC 48VDC
INVERTER OUTPUT
Rated Power 4000VA / 4000W 6000VA / 6000W
Surge Power 8000W 12000W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 92%
Transfer Time 10ms(UPS / VDE4105) / 20ms(APL)/ < 50ms typical (For parallel operation)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage 24VDC 48VDC
Floating Charge Voltage 27.4VDC 54.8VDC
Overcharge Protection 30VDC 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 500VDC (450V for parallel)
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 5000W 6000W
PV Array MPPT Voltage Range 90~430VDC 120~430 VDC
Maximum Solar Charge Current 100A 120A
Maximum AC Charge Current 80A 100A
Maximum Charge Current 100A 120A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 322*486*134 309*505*147
Package Dimension (W*H*D)(mm) 575*229*425 603*260*400
N.W (kg) 9.5 12.5
G.W (kg) 12 13.8
OTHER
Humidity 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature 0°C~50°C
Storage Temperature -15°C~60°C
Communication Interface USB/ WIFI
Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2020+A11:2020
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2018, EN IEC62109-1:2010, EN IEC62109-2:2011
]]> PV1900 EXP Series (6.2-12KW) https://www.mustpower.com/product/pv1900-exp-series-6-2-12kw/ Wed, 06 Mar 2024 11:29:51 +0000 https://www.mustpower.com/?post_type=product&p=23945 High Frequency solar Inverter DC 48V | PV 500V | 120/150A | Dual output PV1900 EXP is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PV1900 EXP Series can run without battery. The Maximum PV input voltage can reach 500V and MPPT voltage range is 90~450Vdc, built-in two MPPTs solar charge controller, which can help customers make full use of solar energy.]]> ■ Dual output for smart load management
■ Smart color LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in Two MPPTs solar charge controller
■ Wide MPPT voltage range is 90~450V, the maximum PV input voltage can reach 500V (450V for parallel)
■ Can provide the power to the load without battery
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ With BMS lithium battery communication function
■ With AC/PV lithium battery activation function
■ Support USB, RS485 monitoring function
■ Parallel operation up to 6 units
■ WIFI remote monitoring

MODEL PV19-6248 EXP PV19-8048 EXP PV19-10048 EXP PV19-11048 EXP PV19-12048 EXP
Default Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 6200VA/6200W 8000VA/8000W 10000VA/10000W 11000VA/11000W 12000VA/12000W
Surge Power 12400W 16000W 20000W 22000W 24000W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 92%
Transfer Time 10ms(UPS / VDE4105) / 20ms(APL)
AC INPUT
Voltage 230VAC
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 500VDC (450V for parallel)
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 4000W*2 4000W*2 5000W*2 6000W*2 6000W*2
Maximum PV Input Current 18A*2 18A*2 27A*2(40A max) 27A*2(40A max) 27A*2(40A max)
PV Array MPPT Voltage Range 90~450VDC (90~430VDC for parallel)
Maximum Solar Charge Current 120A 120A 150A 150A 150A
Maximum AC Charge Current 100A 120A 150A 150A 150A
Maximum Charge Current 120A 120A 150A 150A 150A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D) 425*473*145mm 425*527*145mm
Package Dimension (W*H*D) / / / / /
N.W (kg) / / / / /
G.W (kg) / / / / /
OTHER
Humidity 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature Range 0°C~50°C
Storage Temperature Range -15°C ~60°C
Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2020+A11:2020
CE-LVD (IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2018, EN IEC62109-1:2010, EN IEC62109-2:2011
]]>
