Off Grid Power Inverter – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Wed, 04 Dec 2024 06:31:49 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 PI1500 Series (600-2000W) https://www.mustpower.com/product/pi1500-series-600-2000w/ Wed, 04 Dec 2024 06:31:49 +0000 https://www.mustpower.com/?post_type=product&p=24800 Car Inverter PI1500 series is a pure sine wave inverter, high frequency machine solution, the product is small size, the solution is reliable and stable, the main function is to invert the DC 12VDC battery or 24VDC battery to AC 230VAC output, mainly used for emergency use Electricity, car inverter, outdoor electricity and other occasions.]]> ■ Input Voltage 12V / 24V DC optional
■ Output Voltage 230V AC optional
■ Portable power for AC products, AC outlets for connecting multiple loads
■ High efficiency converts virtually all of the battery’s power to AC
■ Mounting brackets for convenient installation
■ Overload and over temperature shut down
■ Low voltage and over voltage alarm/cut off
■ Short circuit protection

MODEL PI15-0612 PI15-0624 PI15-1012 PI15-1024 PI15-1512 PI15-1524 PI15-2012 PI15-2024
BATTERY DC INPUT
Input Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC
Low Voltage Protect Delay 2 seconds
Low Voltage Warning (PB) 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC
(LI) 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC
Low Voltage Protect (PB) 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC
(LI) 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC
Low Voltage Restoring (PB) 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 23.0VDC 12.5VDC 23.0VDC
(LI) 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC
Over Voltage Protect (PB) 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC
(LI) 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC
Over Voltage Restoring (PB) 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC
(LI) 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power 600W 1000W 1500W 2000W
Peak Power 1200W 2000W 3000W 4000W
Output AC Voltage 230V
Output AC Frequency 50Hz
Output Wave Pure Sine Wave
Output Wave THD < 3%
PROTECTION
Battery Input Protection Low Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output Protection Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED Digital Display Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USB USB-A type (5V2A)
COMMUNICATION
PC USB-B type
EFFICIENCY
Peak Conversion efficiency 91% 90% 88% 90% 88% 90%
ENVIRONMENT
Protection Degree IP20
Working Environment Indoor Fan cooling
Environmental temperature 0~45°C
Ambient humidity 20%-90%, No condensation
Altitude ≤3000m
DIMENSIONS
Machine Dimension (W*H*D)(mm) 261*133*79 314*195*80 415*220*82
Package Dimension (W*H*D)(single) 302*205*140 374*267*147 450*296*150
Package Dimension (W*H*D) 629*425*295(8pcs) 773*560*315(8pcs) 630*495*325(4pcs)
N.W(kg) (machine) 1.4 2.3 4.6
CERTIFICATION & STANDARDS
Coming soon
]]> EP1800 LV Series (3KW) https://www.mustpower.com/product/ep1800-lv-series-3kw/ Fri, 24 May 2024 07:06:25 +0000 https://www.mustpower.com/?post_type=product&p=24287 High Frequency Power Inverter/Charger DC 24V | AC 120V This is a multi-function inverter/charger, combining functions of inverter, battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC charger priority, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter
■ Configurable input voltage range for home appliances and personal computers via LCD setting
■ Configurable battery charging current based on applications via LCD setting
■ Configurable AC Charger via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/ Over temperature/ short circuit protection
■ Smart battery charger design for optimized battery performance
■ Acid or Lithium select
■ Parallel operation with up to 3 units
■ WIFI remote monitoring (optional)
■ With BMS lithium battery communication function (CAN port)

MODEL EP18-3024LV
Rated output power 3000VA/3000W
Surge Power 6000W
AC INPUT
Nominal Input Voltage 120Vac±5%
Selectable Voltage range 90~145VAC(UPS) / 74~145VAC(APL) / 108~132VAC(UL)
Frequency Range 50Hz/60Hz (Auto sensing)
Inverter Efficiency(Peak) 95%
INVERTER OUTPUT
Output voltage waveform Pure sine wave
Output Voltage Regulation 120Vac ± 5%
Output Frequency 50Hz / 60Hz(Auto sensing)
Power Factor ≈1
Transfer Time 10ms (UPS / UL) / 20ms (APL) <50ms(For parallel operation)
Nominal DC Input Voltage 24VDC
Cold Start Voltage 23VDC
Output Short Circuit Protection Line mode Circuit Breaker
Battery mode Electronic Circuits
BATTERY
Battery voltage 24VDC
Floating voltage 27.4V
Overcharge Protection 30V
CHARGER
Charging Current(UPS) @Nominal Input Voltage Default:30A; MAX:80A
Bulk Charging Voltage 28.8Vdc
Floating Charging Voltage 27.4Vdc
Charging Algorithm 3-Step
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 297.5*468*125
Package Dimension (W*H*D)(mm) /
N.W(kg) /
G.W(kg) /
GENERAL
Mounting Wall mount
Display LED+LCD
Parallel operation 3 units
Operation Temperature Range -10°C to 50°C
Storage Temperature -15°C to 60°C
Standard Warranty 2 years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-4,EN6100-6-2+EN IEC62109-1)
]]> EP1800 PRO Series (5.2KW) https://www.mustpower.com/product/ep1800-pro-series-5-2kw/ Wed, 24 Apr 2024 04:03:06 +0000 https://www.mustpower.com/?post_type=product&p=24160 High Frequency Power Inverter/Charger This is a multi-function inverter/charger, combining functions of inverter, battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC charger priority, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter
■ Configurable input voltage range for home appliances and personal computers via LCD setting
■ Configurable battery charging current based on applications via LCD setting
■ Configurable AC Charger via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/ Over temperature/ short circuit protection
■ Smart battery charger design for optimized battery performance
■ Acid or Lithium select
■ Parallel operation with up to 3 units
■ WIFI remote monitoring (optional)
■ With BMS lithium battery communication function (CAN port)

MODEL EP18-5248 PRO
Rated output power 5200VA/5200W
Surge Power 10400W
AC INPUT
Nominal Input Voltage 230Vac±5%
Selectable Voltage range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz/60Hz (Auto sensing)
Inverter Efficiency(Peak) 90%
INVERTER OUTPUT
Output voltage waveform Pure sine wave
Output Voltage Regulation 230Vac ± 5%
Output Frequency 50Hz / 60Hz(Auto sensing)
Power Factor ≈1
Transfer Time 10ms (UPS / VDE4105) / 20ms (APL) <50ms(For parallel operation)
Nominal DC Input Voltage 48VDC
Cold Start Voltage 46VDC
Output Short Circuit Protection Line mode Circuit Breaker
Battery mode Electronic Circuits
BATTERY
Battery voltage 48VDC
Floating voltage 54.8V
Overcharge Protection 60V
CHARGER
Charging Current(UPS) @Nominal Input Voltage Default:30A; MAX:80A
Bulk Charging Voltage 56.4Vdc
Floating Charging Voltage 54Vdc
Charging Algorithm 3-Step
GENERAL
Mounting Wall mount
Display LED+LCD
Parallel operation 3 units
Operation Temperature Range -10℃ to 50℃
Storage Temperature -15℃ to 60℃
Standard Warranty 1 year
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D) 297.5*468*125mm
CERTIFICATION & STANDARDS
CE
]]> EH2900 LV Series (AC:110V 300-1000W) https://www.mustpower.com/product/eh2900-lv-series-ac110v-300-1000w/ Tue, 23 Apr 2024 11:16:54 +0000 https://www.mustpower.com/?post_type=product&p=24134 Off Grid Inverter Charger 12V/24V | 10~30A | AC 120V EH2900 LV series inverter is a cost effective, intelligent with UPS function. The comprehensive LCD offers user-configurable and easy-accessible button adjustment such as battery charge current, battery charge voltage, frequency, buzzer etc. It's perfect for the user who need a simple and economical inverter,with user-friendly installnation and setting.]]> ■ Sine wave inverter
■ Adjustable charging current from utility
■ Adjustable battery charging current
■ 3 steps charging algorithm
■ Friendly user interface
■ Multi-function display
■ Overload and short-circuit protection
■ Battery reverse polarity protection
■ Deep discharge protection
■ Automatic voltage regulationCommunication with PC

MODEL EH29-0312 LV EH29-0412 LV EH29-0512 LV EH29-0612 LV EH29-0812 LV EH29-1012 LV EH29-0624 LV EH29-0824 LV EH29-1024 LV
Default Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated Power 300W 400W 500W 600W 800W 1000W 600W 800W 1000W
Surge Rating 900VA 1200VA 1500VA 1800VA 2400VA 3000VA 1800VA 2400VA 3000VA
Waveform Pure sine wave
Voltage Regulation Battery mode: 110 or 120VAC Line mode: 95~125VAC
Output Frequency 50Hz / 60Hz
Inverter Frequency (Peak) >75% >81%
Bypass Efficiency >95%
Output Transfer Time 8ms(typical) 12ms(max)
AC INPUT
Voltage 110/120VAC
Selectable Voltage Range 70~140VAC ±5%
Low battery voltage alarm 70VAC ±5%
Low battery voltage recover 75VAC ±5%
High battery voltage alarm 140VAC ±5%
High battery voltage recover 135VAC ±5%
Low Frequency Alarm 45 ±5Hz
Low Frequency Recover 46 ±5Hz
High Frequency Alarm 65 ±5Hz
High Frequncy Recover 64 ±5Hz
Nominal Input Range 50Hz / 60Hz ±5Hz
AC Auto Restart YES
BATTERY
Minimum start voltage Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low battery voltage alarm Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low battery voltage cutoff 10-12.0VDC 20.0-24.0VDC
High battery voltage alarm (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC)
AC CHARGE
Floating Voltage 13.5-14.5VDC 27-29VDC
Boost Voltage 13.8~14.5VDC 27.6~29VDC
Maximum Charge Current 300W 400W 500W 600W 800W 1000W 600W 800W 1000W
10A 10A 15A 20A 25A 30A 10A 15A 15A
BYPASS & PROTECTION
Input Waveform Pure sine wave
Input Frequency 50Hz or 60Hz
Overload Protection >110%~125% Load fault after 60s; >125%~150% Load fault after 3s; >150% Load fault after 500ms
Over Temperature Protection ≥90°C
Bypass Output Protection 15A 250VAC
Output Circuit Protection YES
Battery Reverse Protection Optional
Battery Low Voltage Protection YES
Battery High Voltage Protection YES
Bypass Breaker Rating 15A
Maximum Bypass Current 15A
MECHANICAL SPECIFICATION
Machine Dimension (W*H*D)(mm) 300.5*319*132.2
Package Dimension (W*H*D)(mm) 391*187*325
N.W(kg) /
G.W(kg) /
GENERAL
Operating Temperature 0°C~40°C 0~90% relative humidity (non-condensing)
Storage Temperature -15°C to 55°C
Altitude ≤1000M
Audible Noise ≤60dB
Display LED+LCD
Cooling Mode Fan cooling
Fan Starting >45°Cstarting, <30°C Closing
Communication USB
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-LVD (EN IEC62109-1:2010,EN IEC62109-2:2011);CE-EMC+LVD (EN6100-6-4:2007, EN6100-6-2:2005+EN IEC62109-1:2010, EN IEC62109-2:2011) IEC60950-1:2005A+1:2009+A2:2013; EN IEC62040-1:2019
]]> EP2000 Pro Black Series (DC:24V 300-1000W) https://www.mustpower.com/product/ep2000-pro-black-series-dc24v-300-1000w/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23947 Inverter Charger 300W~1000W | 24V | 5~15A EP2000 PRO series inverter is a cost effective, intelligent with UPS function. The comprehensive LCD offers user-configurable and easy-accessible button adjustment such as battery charge current, battery charge voltage, frequency, buzzer etc. It's perfect for the user who need a simple and economical inverter,with user-friendly installnation and setting.Tower and rack design available for different choices.]]> ■ Pure sine wave output

■ Smart LCD setting ( frequency , charge voltage,charge current, etc).

■ 3 steps charging algorithm

■ Built in AVR function

■ Overload and short-circuit protection

■ Battery reverse polarity protection (Optional)

■ Deep discharge protection

■ Cold start function

MODEL EP20-0312 PRO EP20-0612 PRO EP20-0812 PRO EP20-1012 PRO EP20-0324 PRO EP20-0624 PRO EP20-0824 PRO EP20-1024 PRO
Default Battery System Voltage 12VDC 24VDC
INVERTER OUTPUT
Rated Power 300W 600W 800W 1000W 300W 600W 800W 1000W
Surge Rating 900VA 1800VA 2400VA 3000VA 900VA 1800VA 2400VA 3000VA
Waveform Pure sine wave
Voltage Regulation Battery mode: 220 or 230VAC Line mode: 220~240VAC
Output Frequency 50Hz / 60Hz
Inverter Frequency (Peak) >75% >81%
Bypass Efficiency >95%
Output Transfer Time Typical:8ms 12ms(max)
AC INPUT
Voltage 220 / 230 / 240VAC
Selectable Voltage Range 140~280VAC ±5%
Low Battery Alarm 140VAC ±5%
Low Voltage Recover 150VAC ±5%
High Battery Alarm 280VAC ±5%
High Voltage Recover 270VAC ±5%
Low Frequency Alarm 45 ±5Hz
Low Frequency Recover 46 ±5Hz
High Frequency Alarm 65 ±5Hz
High Frequncy Recover 64 ±5Hz
Nominal Input Range 50Hz / 60Hz ±5Hz
AC Auto Restart YES
BATTERY
Minimum Start Voltage Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low Battery Voltage Alarm Low Battery Voltage Cutoff+0.5V Low Battery Voltage Cutoff+1.0V
Low Battery Voltage Cut Off 10-12.0VDC 20.0-24.0VDC
High Battery Voltage Alarm (13.8-14.5V)+1V for 12VDC mode (*2 for 24VDC)
AC CHARGE
Floating Voltage 13.5-14.5VDC 27-29VDC
Boost Voltage 13.8~14.5VDC 27.6~29VDC
Maximum Charge Current 300W 600W 800W 1000W 300W 600W 800W 1000W
10A 20A 25A 30A 5A 10A 15A 15A
BYPASS & PROTECTION
Input Waveform Pure sine wave
Input Frequency 50Hz or 60Hz
Overload Protection 110%~125% Load foult affter 60s; 125%~150% Load foult affter 3s; >150% Load fault after 500ms
Over Temperature Protection ≥90°C
Bypass Output Protection 10A 250VAC
Output Circuit Protection YES
Battery Reverse Protection Optional
Battery Low Voltage Protection YES
Battery High Voltage Protection YES
Bypass Breaker Rating 10A
Maximum Bypass Current 10A
MECHANICAL SPECIFICATION
Machine Dimension (W*H*D)(mm) 315*145*210
N.W(kg) 300W 600W 800W 1000W 300W 600W 800W 1000W
7.5 10.7 12.5 13.5 7.5 10.7 12.5 13.5
Package Dimension (W*H*D)(mm) 420*280*225
G.W(kg) 300W 600W 800W 1000W 300W 600W 800W 1000W
8 11.5 13 14.0 8 11.5 13 14
OTHER
Operating Temperature 0°C~40°C 0~90% relative humidity (non-condensing)
Storage Temperature -15°C to 55°C
Altitude ≤1000M
Audible Noise ≤60dB
Display LED+LCD
Cooling Mode Fan cooling
Fan Starting >45°C starting, <30°C Closing
Communication USB
CERTIFICATION & STANDARDS
CE-LVD (EN IEC62109-1:2010,EN IEC62109-2:2011)
CE-EMC+LVD (EN6100-6-4:2007, EN6100-6-2:2005+EN IEC62109-1:2010, EN IEC62109-2:2011)
IEC60950-1:2005A+1:2009+A2:2013 EN IEC62040-1:2019
]]> PI1500 LV Series (AC:120V 300W) https://www.mustpower.com/product/pi1500-lv-series-ac120v-300w/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23953 Pure Sine Wave Power Inverter 300W | DC 12V,24V | AC 120V PI1500 series is a pure sine wave inverter, high frequency machine solution, the product is small size, the solution is reliable and stable, the main function is to invert the DC 12VDC battery or 24VDC battery to AC 120VAC output, mainly used for emergency use Electricity, car inverter, outdoor electricity and other occasions.]]> ■ Input Voltage 12V / 24V DC optional

■ Output Voltage 120V AC optional

■ Portable power for AC products, AC outlets for connecting multiple loads

■ High efficiency converts virtually all of the battery’s power to AC

■ Mounting brackets for convenient installation

■ Overload and over temperature shut down

■ Low voltage and over voltage alarm/cut off

■ Short circuit protection

MODEL PI15-0312 LV PI15-0324 LV PI15-0612 LV PI15-0624 LV PI15-1012 LV PI15-1024 LV PI15-1512 LV PI15-1524 LV PI15-2012 LV PI15-2024 LV
BATTERY DC INPUT
Input Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC
Low Voltage Protect Delay 2 seconds
Low Voltage Warning (PB) 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC
(LI) 10.5VDC 21.0VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC
Low Voltage Protect (PB) 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC
(LI) 11.5VDC 23.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC
Low Voltage Restoring (PB) 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 23.0VDC 12.5VDC 23.0VDC
(LI) 12.5VDC 25.0VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC
Over Voltage Protect (PB) 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC
(LI) 14.7VDC 29.4VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC
Over Voltage Restoring (PB) 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC
(LI) 15.0VDC 30.0VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power 300W 600W 1000W 1500W 2000W
Peak Power 600W 1200W 2000W 3000W 4000W
Output AC Voltage 120V 120V 120V 120V 120V
Output AC Frequency 60Hz 60Hz 60Hz 60Hz 60Hz
Output Wave Pure Sine Wave
Output Wave THD < 3%
PROTECTION
Battery Input Protection Low Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output Protection Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED Display Red: Error ; Green: System OK
LED Digital Display / Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USB USB-A type (5V1A)
EFFICIENCY
Peak Conversion efficiency 91% 91% 90% 88% 90% 88% 90%
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 205*125*61 242*158*81 291*220*83 380.8*248*90
Package Dimension (W*H*D)(mm) 228*102*176 268*140*205 330*147*267 420*150*300
N.W(kg) 1 1.7 2.6 4.5
G.W(kg) 9.3 (8pcs) 15 (8pcs) 23 (8pcs) 19 (4pcs)
OTHER
Protection Degree IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
Working Environment Indoor Fan cooling
Environmental temperature 0~45°C
Ambient humidity 20%-90%, No condensation
Altitude ≤3000m
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) CE-LVD(EN 62477-1/A11)
]]> PI1500 LV Series (AC:120V 600W) https://www.mustpower.com/product/pi1500-lv-series-ac120v-600w/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23954 Pure Sine Wave Power Inverter 600W | DC 12V,24V | AC 120V PI1500 series is a pure sine wave inverter, high frequency machine solution, the product is small size, the solution is reliable and stable, the main function is to invert the DC 12VDC battery or 24VDC battery to AC 120VAC output, mainly used for emergency use Electricity, car inverter, outdoor electricity and other occasions.]]> ■ Input Voltage 12V / 24V DC optional

■ Output Voltage 120V AC optional

■ Portable power for AC products, AC outlets for connecting multiple loads

■ High efficiency converts virtually all of the battery’s power to AC

■ Mounting brackets for convenient installation

■ Overload and over temperature shut down

■ Low voltage and over voltage alarm/cut off

■ Short circuit protection

MODEL PI15-0312 LV PI15-0324 LV PI15-0612 LV PI15-0624 LV PI15-1012 LV PI15-1024 LV PI15-1512 LV PI15-1524 LV PI15-2012 LV PI15-2024 LV
BATTERY DC INPUT
Input Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC
Low Voltage Protect Delay 2 seconds
Low Voltage Warning (PB) 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC
(LI) 10.5VDC 21.0VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC
Low Voltage Protect (PB) 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC
(LI) 11.5VDC 23.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC
Low Voltage Restoring (PB) 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 23.0VDC 12.5VDC 23.0VDC
(LI) 12.5VDC 25.0VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC
Over Voltage Protect (PB) 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC
(LI) 14.7VDC 29.4VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC
Over Voltage Restoring (PB) 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC
(LI) 15.0VDC 30.0VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power 300W 600W 1000W 1500W 2000W
Peak Power 600W 1200W 2000W 3000W 4000W
Output AC Voltage 120V 120V 120V 120V 120V
Output AC Frequency 60Hz 60Hz 60Hz 60Hz 60Hz
Output Wave Pure Sine Wave
Output Wave THD < 3%
PROTECTION
Battery Input Protection Low Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output Protection Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED Display Red: Error ; Green: System OK
LED Digital Display / Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USB USB-A type (5V1A)
EFFICIENCY
Peak Conversion efficiency 91% 91% 90% 88% 90% 88% 90%
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 205*125*61 242*158*81 291*220*83 380.8*248*90
Package Dimension (W*H*D)(mm) 228*102*176 268*140*205 330*147*267 420*150*300
N.W(kg) 1 1.7 2.6 4.5
G.W(kg) 9.3 (8pcs) 15 (8pcs) 23 (8pcs) 19 (4pcs)
OTHER
Protection Degree IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
Working Environment Indoor Fan cooling
Environmental temperature 0~45°C
Ambient humidity 20%-90%, No condensation
Altitude ≤3000m
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) CE-LVD(EN 62477-1/A11)
]]> PI1500 LV Series (AC:120V 1000W) https://www.mustpower.com/product/pi1500-lv-series-ac120v-1000w/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23955 Pure Sine Wave Power Inverter 1000W | DC 12V,24V | AC 120V PI1500 series is a pure sine wave inverter, high frequency machine solution, the product is small size, the solution is reliable and stable, the main function is to invert the DC 12VDC battery or 24VDC battery to AC 120VAC output, mainly used for emergency use Electricity, car inverter, outdoor electricity and other occasions.]]> ■ Input Voltage 12V / 24V DC optional

■ Output Voltage 120V AC optional

■ Portable power for AC products, AC outlets for connecting multiple loads

■ High efficiency converts virtually all of the battery’s power to AC

■ Mounting brackets for convenient installation

■ Overload and over temperature shut down

■ Low voltage and over voltage alarm/cut off

■ Short circuit protection

MODEL PI15-0312 LV PI15-0324 LV PI15-0612 LV PI15-0624 LV PI15-1012 LV PI15-1024 LV PI15-1512 LV PI15-1524 LV PI15-2012 LV PI15-2024 LV
BATTERY DC INPUT
Input Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC
Low Voltage Protect Delay 2 seconds
Low Voltage Warning (PB) 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC
(LI) 10.5VDC 21.0VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC
Low Voltage Protect (PB) 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC
(LI) 11.5VDC 23.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC
Low Voltage Restoring (PB) 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 23.0VDC 12.5VDC 23.0VDC
(LI) 12.5VDC 25.0VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC
Over Voltage Protect (PB) 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC
(LI) 14.7VDC 29.4VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC
Over Voltage Restoring (PB) 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC
(LI) 15.0VDC 30.0VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power 300W 600W 1000W 1500W 2000W
Peak Power 600W 1200W 2000W 3000W 4000W
Output AC Voltage 120V 120V 120V 120V 120V
Output AC Frequency 60Hz 60Hz 60Hz 60Hz 60Hz
Output Wave Pure Sine Wave
Output Wave THD < 3%
PROTECTION
Battery Input Protection Low Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output Protection Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED Display Red: Error ; Green: System OK
LED Digital Display / Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USB USB-A type (5V1A)
EFFICIENCY
Peak Conversion efficiency 91% 91% 90% 88% 90% 88% 90%
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 205*125*61 242*158*81 291*220*83 380.8*248*90
Package Dimension (W*H*D)(mm) 228*102*176 268*140*205 330*147*267 420*150*300
N.W(kg) 1 1.7 2.6 4.5
G.W(kg) 9.3 (8pcs) 15 (8pcs) 23 (8pcs) 19 (4pcs)
OTHER
Protection Degree IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
Working Environment Indoor Fan cooling
Environmental temperature 0~45°C
Ambient humidity 20%-90%, No condensation
Altitude ≤3000m
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) CE-LVD(EN 62477-1/A11)
]]> PI1500 LV Series (AC:120V 1.5-2KW) https://www.mustpower.com/product/pi1500-lv-series-ac120v-1-5-2kw/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23956 Pure Sine Wave Power Inverter 1.5-2KW | DC 12V,24V | AC 120V PI1500 series is a pure sine wave inverter, high frequency machine solution, the product is small size, the solution is reliable and stable, the main function is to invert the DC 12VDC battery or 24VDC battery to AC 120VAC output, mainly used for emergency use Electricity, car inverter, outdoor electricity and other occasions.]]> ■ Input Voltage 12V / 24V DC optional

■ Output Voltage 120V AC optional

■ Portable power for AC products, AC outlets for connecting multiple loads

■ High efficiency converts virtually all of the battery’s power to AC

■ Mounting brackets for convenient installation

■ Overload and over temperature shut down

■ Low voltage and over voltage alarm/cut off

■ Short circuit protection

MODEL PI15-0312 LV PI15-0324 LV PI15-0612 LV PI15-0624 LV PI15-1012 LV PI15-1024 LV PI15-1512 LV PI15-1524 LV PI15-2012 LV PI15-2024 LV
BATTERY DC INPUT
Input Voltage 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC 12VDC 24VDC
Low Voltage Protect Delay 2 seconds
Low Voltage Warning (PB) 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC 10.5VDC 21.0VDC
(LI) 10.5VDC 21.0VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC 11.6VDC 23.2VDC
Low Voltage Protect (PB) 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC 11.5VDC 23.0VDC
(LI) 11.5VDC 23.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC 12.0VDC 24.0VDC
Low Voltage Restoring (PB) 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 25.0VDC 12.5VDC 23.0VDC 12.5VDC 23.0VDC
(LI) 12.5VDC 25.0VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC 12.8VDC 25.6VDC
Over Voltage Protect (PB) 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC 14.7VDC 29.4VDC
(LI) 14.7VDC 29.4VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC 14.5VDC 29.0VDC
Over Voltage Restoring (PB) 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC 15.0VDC 30.0VDC
(LI) 15.0VDC 30.0VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC 14.8VDC 29.6VDC
Parameters: (PB) Lead-acid Battery / (Ll) 4 series (12V), 8 series (24V) LiFePO4 Lithium Battery Pack
INVERTER AC OUTPUT
Default Power 300W 600W 1000W 1500W 2000W
Peak Power 600W 1200W 2000W 3000W 4000W
Output AC Voltage 120V 120V 120V 120V 120V
Output AC Frequency 60Hz 60Hz 60Hz 60Hz 60Hz
Output Wave Pure Sine Wave
Output Wave THD < 3%
PROTECTION
Battery Input Protection Low Voltage Protection, Over Voltage Protection, Reverse Protection
Inverter Output Protection Output Overload, Short-Circuit, Over Temperature Protection
DISPLAY
LED Display Red: Error ; Green: System OK
LED Digital Display / Display Battery Voltage, Output Power, Output Voltage, Error Numbers
DC OUTPUT
USB USB-A type (5V1A)
EFFICIENCY
Peak Conversion efficiency 91% 91% 90% 88% 90% 88% 90%
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 205*125*61 242*158*81 291*220*83 380.8*248*90
Package Dimension (W*H*D)(mm) 228*102*176 268*140*205 330*147*267 420*150*300
N.W(kg) 1 1.7 2.6 4.5
G.W(kg) 9.3 (8pcs) 15 (8pcs) 23 (8pcs) 19 (4pcs)
OTHER
Protection Degree IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
Working Environment Indoor Fan cooling
Environmental temperature 0~45°C
Ambient humidity 20%-90%, No condensation
Altitude ≤3000m
Standard Warranty 2 year
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3, EN6100-6-1+EN IEC62109-1, EN IEC62109-2) CE-LVD(EN 62477-1/A11)
]]> EP5000 PRO Rack Series (5.2KW) https://www.mustpower.com/product/ep5000-pro-rack-series-5-2kw/ Wed, 06 Mar 2024 11:29:52 +0000 https://www.mustpower.com/?post_type=product&p=23961 High Frequency Inverter 5.2KW | 230V | WIFI This is a multi-function inverter/charger ,combining Functions of inverter, battery charger to offfer uninte uninterruptible power with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC charger, and acceptable input voltage based on different applications.]]> ■ Pure sine wave inverter
■ Configurable input voltage range For home appliances and personal computers via LCD setting Configurable battery charging current based on applications via LCD setting
■ Configurable AC Charger via LCD setting
■ Compatible to mains voltage or generator power
■ Auto restart while AC is recovering
■ Overload/Over temperature/short circuit protection
■ Smart battery charger design For optimized battery performance
■ Cold start Function
■ WIFI remote monitoring (optional)

MODEL EP50-5248 PRO
Rated output power 5200VA/5200W
AC INPUT
Nominal Input Voltage 230Vac±5%
Selectable Voltage range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105)
Frequency Range 50Hz/60Hz (Auto sensing)
Inverter Efficiency(Peak) 90%
INVERTER OUTPUT
Output voltage waveform Pure sine wave
Output Voltage Regulation 230Vac ± 5%
Output Frequency 50Hz / 60Hz(Auto sensing)
Power Factor ≈1
Transfer Time 10ms (UPS / VDE4105) / 20ms (APL) （50ms(For parallel operation)
Nominal DC Input Voltage 48VDC
Cold Start Voltage 46VDC
Output Short Circuit Protection Line mode Circuit Breaker
Battery mode Electronic Circuits
BATTERY
Battery voltage 48VDC
Floating voltage 54.8V
Overcharge Protection 60V
CHARGER
Charging Current(UPS) @Nominal Input Voltage Default:30A; MAX:80A
Bulk Charging Voltage 56.4Vdc
Floating Charging Voltage 54Vdc
Charging Algorithm 3-Step
GENERAL
Mounting Rack mount
Display LED+LCD
Parallel operation 3 units
Operation Temperature Range -10°C to 50°C
Storage Temperature -15°C to 60°C
Machine Dimension (W*H*D) 468*86.3*400mm
Package Dimension (W*H*D) /
N.W 11kg
G.W /
CERTIFICATION & STANDARDS
CE
]]>
