MPPT Solar Charge Controller – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Tue, 12 Nov 2024 06:29:45 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 PC1600A Series (20/30/40A) https://www.mustpower.com/product/pc1600a-series-20-30-40a/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23930 MPPT Solar Charge Controller MPPT (Maximum Power Point Tracking)Solar Charge Controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array. Each Charge Controller allows customized battery recharging.]]> ■ LCD display , easy to operate on LCD screen
■ Multi stage charging (3-stage charging , parallel charging and equalized charging function)
■ BTS – Battery remote temperature sensor terminal
■ Enable to charge Li-thium, Gel , lead-acid battery
■ With RS485 & USB communication port
■ Protection: PV array short circuit, PV reverse polarity, Battery reverse polarity, Over charging, Output short circuit

MODEL PC16-2015A PC16-3015A PC16-4015A
Nominal Battery System Voltage 12VDC / 24VDC (Auto Detection)
CONTROLLER INPUT
PV Open Circuit Voltage 12V 100VDC
24V 145VDC
PV Array MPPT Voltage Range 12V 16VDC~100VDC
24V 32VDC~130VDC
Max
PV Input Power		 12V 300W 450W 600W
24V 600W 900W 1200W
BATTERY
Absorption Voltage 12V 12.5VDC
24V 25.0VDC
Refloat Voltage 12V 13.7VDC
24V 27.4VDC
Float Voltage 12V 14.3VDC
24V 28.6VDC
Low Voltage Protection Point 12V 10.0VDC
24V 20.0VDC
DC OUTPUT
Output Voltage 12V 10.0~14.5VDC
24V 20.0~29.0VDC
Peak Conversion Efficiency 98%(MPPT Efficiency 99%)
Max Charging Current 20 amps continuous 30 amps continuous 40 amps continuous
Max Output Current 20 amps continuous 20 amps continuous 20 amps continuous
Low Voltage alarm 12V 10.25VDC
24V 20.5VDC
Low Voltage
cut off		 12V 10.0VDC
24V 20.0 VDC
Low Voltage Recovery 12V 11.0VDC
24V 22.0VDC
DISPLAY & PROTECTION
LED Indication Systematic operation, LV indication, LV protection, Over charge protection Loads protection, Short circuit protection
LED Display Charge Voltage, Charge Current, Voltage of storage battery, Capacity of storage battery, Output current
Alarm Protections PV array short circuit, PV reverse polarity
Battery reverse polarity, Over charging protrction
Output short circuit protection
Low voltage protection for storage battery
MECHANICAL SPECIFICATIONS
Mounting Wall mount
Machine Dimension (W*H*D)(mm) 154*236*88
Package Dimension (W*H*D)(mm) / / /
N.W(kg) /
G.W(kg) / / /
OTHER
Environmental Rating Indoor
Radiating Mode Automatic cooling
Operating Temperature Range 0°C~ 55°C
Loading (20GP/40GP/40HQ) 2500pcs / 5000pcs / 5800pcs
CERTIFICATION & STANDARDS
UKCA (BS IEC62109-1:2010)+CE-LVD(EN IEC62109-1:2010)
CE-EMC+LVD (EN6100-6-3:2007+A1:2011,EN6100-6-1:2019+EN IEC62109-1:2010)
]]> PC1800A Series (60/80A) https://www.mustpower.com/product/pc1800a-series-60-80a/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23931 MPPT Solar Charge Controller MPPT (Maximum Power Point Tracking)Solar Charge Controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array. Each Charge Controller allows customized battery recharging.]]> ■ LCD display , easy to operate on LCD screen
■ Multi stage charging (3-stage charging , parallel charging and equalized charging function)
■ BTS – Battery remote temperature sensor terminal
■ Enable to charge Li-thium, Gel , lead-acid battery
■ With RS485 & USB communication port
■ Protection: PV array short circuit, PV reverse polarity, Battery reverse polarity, Over charging, Output short circuit

MODEL PC18-6015A PC18-8015A
Nominal Battery System Voltage 12V / 24V / 48VDC (Auto detection); 36V (Setting)
ELECTRICAL SPECIFICATIONS
Maximum Battery Current 60Amps 80Amps
Battery Voltage 12V/ 24V/ 36V/ 48V
Maximum Solar Input Voltage 12V (VBAT) 100V
24V (VBAT) 145V
36V (VBAT) 145V
48V (VBAT) 145V
PV Array MPPT Voltage Range 12V (VBAT) 15~95V
24V (VBAT) 30~130V
36V (VBAT) 45~130V
48V (VBAT) 60~130V
Maximum Input Power 12V (VBAT) 940W 1250W
24V (VBAT) 1880W 2500W
36V (VBAT) 2820W 3750W
48V (VBAT) 3760W 5000W
Protections Solar high voltage disconnect; Solar high voltage reconnect; Battery high voltage disconnect; Battery high voltage reconnect; High temperature disconnect;High temperature reconnect
BATTERY CHARGING
Charging Algorithm 3-Step or 4-Step (Li)
Temperature Compensation Coefficient -5mV / °C/ cell (25°C ref.)
Temperature Compensation Set Points Absorption, Float
Charging Set Points Flooded Battery Absorption Stage 14.2V/ 28.4V/ 42.6V/ 56.8V
Float Stage 13.7V/ 27.4V/ 41.1V/ 54.8V
AGM/ GEL/ LEAD
Battery (Default)		 Absorption Stage 14.4V/ 28.8V/ 43.2V/ 57.6V
Float Stage 13.7V/ 27.4V/ 41.1V/ 54.8V
Over-charging Voltage 15.5V / 30.0V / 45.0V / 60.0V
Over-charging Comeback Voltage 14.5V / 29.5V / 44.5V / 59.0V
Battery Defect Voltage 10.0V / 17.0V / 25.5V / 34.0V
MECHANICAL & ENVIRONMENT
Machine Dimension (W*H*D)(mm) 315*160*135
Package Dimension (W*H*D)(mm) /
N.W(kg) /
G.W(kg) /
Operating Temperature Range -10°Cto 55°C
Storage Temperature -40°Cto 75°C
Humidity 0%~90% RH (No condensing)
Enclosure IP20
CERTIFICATION & STANDARDS
UKCA (BS IEC62109-1:2010)+CE-LVD(EN IEC62109-1:2010)
CE-EMC+LVD (EN6100-6-3:2007+A1:2011,EN6100-6-1:2019+EN IEC62109-1:2010)
]]> PC1800A Series (30/40A) https://www.mustpower.com/product/pc1800a-series-30-40a/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23932 MPPT Solar Charge Controller 30A, 40A | DC 12V,24V | PV 145V This solar charge controller is an advanced solar charger with maximum power point tracking. Applying intelligent MPPT algorithm, it allows solar charge controller to extract maximum power from solar arrays by finding the maximum power point of the array. The MPPT battery charging process has been optimized for long battery life and improved system performance. Self-diagnostics and electronic error protections prevent damage when installation errors or system faults occur.]]> ■ Intelligent Maximum Power Point Tracking technology increases efficiency 25%~30%
■ Compatible for PV systems in 12V,or24V
■ Three-stage charging optizes battery performance
■ Maximum charging current up to 30A/40A
■ Advanced MPPT technology,with efficient no less than 99%
■ Maximum DC- DC conversion efficiency of 98%
■ Battery temperature sensor(BTS) automatically provides temperature compensation Automatic battery voltage detection
■ Integrated intelligent slot compatible with 485 communication

MODEL PC18-3015A PC18-4015A
Nominal Battery System Voltage 12V / 24V (Auto detection)
CONTROLLER INPUT
Battery Voltage 12V/ 24V
Open circuit voltage 145V
PV Array MPPT Voltage Range 60-130VDC
Maximum Input Power 12V 432W 576W
24V 864W 1152W
BATTERY
Charging Set Points Flooded Battery Absorption Stage 14.2V/28.4V
Float Stage 13.7V/27.4V
AGM/GEL/LEAD
(Default)		 Absorption Stage 14.4V/28.8V
Float Stage 13.7V/27.4V
Over-charging Voltage 15.5V / 30.0V
Over-charging Comeback Voltage 14.5V / 29.5V
Battery Defect Voltage 10.0V / 17.0V
Temperature Compensation Coefficient -5mv / °C /cell (25°C vef)
Peak Conversion Efficiency 98% (MPPT Efficiency 99%)
Maximum Battery Current 30A 40A
Max Charging Current 30amps continuous @ 40°C ambient 40amps continuous @ 40°C ambient
GENERAL SPECIFICATION
Radiating Mode Automatic cooling
Protections Solar high voltage disconnect/ Solar high voltage reconnect/ Battery high voltage disconnect Battery high voltage reconnect/ High temperature disconnect/ High temperature reconnect
MECHANICAL SPECIFICATIONS
Mounting Wall mount
Machine Dimension (W*H*D)(mm) 187*255*72mm
Package Dimension (W*H*D)(mm) /
N.W(kg) /
G.W(kg) /
OTHER
Environmental Rating Indoor
Enclosure IP30
Operating Temperature Range -10~50°C
Ambient Humidity 0~90% relative humidity (non-condensing)
Altiude ≤3000m
CERTIFICATION & STANDARDS
UKCA (BS IEC62109-1:2010)+CE-LVD(EN IEC62109-1:2010)
CE-EMC+LVD (EN6100-6-3:2007+A1:2011,EN6100-6-1:2019+EN IEC62109-1:2010)
]]> PC1800F Series (60/80/100A) https://www.mustpower.com/product/pc1800f-series-60-80-100a/ Wed, 06 Mar 2024 11:29:48 +0000 https://www.mustpower.com/?post_type=product&p=23933 MPPT Solar Charge Controller MPPT (Maximum Power Point Tracking)Solar Charge Controller offer an efficient, safe, multi-stage recharging process that prolongs battery life and assures peak performance from a solar array. Each Charge Controller allows customized battery recharging.]]> Features:

■ LCD display , easy to operate on LCD screen
■ Multi stage charging (3-stage charging , parallel charging and equalized charging function)
■ Maximum Solar Input Voltage: 245V
■ BTS – Battery remote temperature sensor terminal
■ Enable to charge Li-thium, Gel , lead-acid battery
■ With RS485 & USB communication port
■ Protection: PV array short circuit, PV reverse polarity, Battery reverse polarity, Over charging, Output short circuit

MODEL PC18-6025F PC18-8025F PC18-10025F
Nominal Battery System Voltage 12V / 24V / 48VDC (Auto detection); 36V (Setting)
CONTROLLER INPUT
Battery Voltage 12V / 24V / 36V / 48V
Maximum Solar Input Voltage 12V (VBAT) 100V
24V (VBAT) 245V
36V (VBAT) 245V
48V (VBAT) 245V
PV Array MPPT Voltage Range 12V (VBAT) 15-95V
24V (VBAT) 30~230V
36V (VBAT) 45~230V
48V (VBAT) 60~230V
Maximum Input Power 12V (VBAT) 940W 1250W 1560W
24V (VBAT) 1880W 2500W 3120W
36V (VBAT) 2820W 3750W 4680W
48V (VBAT) 3760W 5000W 6250W
BATTERY
Charging Set Points Flooded Battery Absorption Stage 14.2V / 28.4V / 42.6V / 56.8V
Float Stage 13.7V / 27.4V / 41.1V / 54.8V
AGM
(Default)		 Absorption Stage 14.4V / 28.8V / 43.2V / 57.6V
Float Stage 13.7V / 27.4V / 41.1V / 54.8V
Over-charging Voltage 15.5V / 30.0V / 45.0V / 60.0V
Over-charging Comeback Voltage 14.5V / 29.5V / 44.5V / 59.0V
Battery Defect Voltage 10.0V / 17.0V / 25.5V / 34.0V
Temperature Compensation Conefficient -5mv / °C /cell (25°C vef)
Peak Conversion Efficiency 98% (MPPT Efficiency 99%)
Maximum Battery Current 60A 80A 100A
Maximum DC load current / / 100A
Max Charging Current 60amps continuous @ 40°C ambient 80amps continuous @ 40°C ambient 100amps continuous @ 40°C ambient
DISPLAY & PROTECTION
Protections Solar high voltage disconnect/ Solar high voltage reconnect/ Battery high voltage disconnect Battery high voltage reconnect/ High temperature disconnect/ High temperature reconnect
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 163.6*306.6*94.9 165*284*97
Package Dimension (W*H*D)(mm) / /
N.W(kg) 3 4
G.W(kg) / /
OTHER
Mounting Wall mount
Environmental Rating Indoor
Enclosure IP20
Radiating Mode Fan cooling
Operating Temperature Range -10~55°C
Ambient Humidity 0~90% relative humidity (non-condensing)
Altiude ≤3000m
CERTIFICATION & STANDARDS
UKCA (BS IEC62109-1:2010)+CE-LVD(EN IEC62109-1:2010)
CE-EMC+LVD (EN6100-6-3:2007+A1:2011,EN6100-6-1:2019+EN IEC62109-1:2010)
]]>
