On/Off Grid Hybrid Solar Inverter – Hybrid Solar Inverter & ESS Manufacturer https://www.mustpower.com Must Energy Storage System Wed, 11 Jun 2025 07:58:51 +0000 en-US hourly 1 https://wordpress.org/?v=6.8.2 PH1100 EU Series (High Voltage 20–50kW) https://www.mustpower.com/product/ph1100-eu-series-high-voltage-20-50kw/ Wed, 11 Jun 2025 07:58:14 +0000 https://www.mustpower.com/?post_type=product&p=25079 ⚡ THREE PHASE HYBRID SOLAR INVERTER 20–50kW | 150–800V High Voltage Battery | Max. PV 1000V The PH1100 EU Series (20–50kW) is a robust three-phase hybrid inverter designed for large residential, commercial, and industrial solar-plus-storage applications. Compatible with high-voltage lithium batteries (150–800V), it empowers users to reduce reliance on the grid while ensuring maximum solar utilization. With advanced time-of-use energy optimization, this system helps users save on electricity bills by storing energy during off-peak hours and discharging during high-tariff periods. It also integrates a built-in UPS function (switch time <10ms) to keep critical loads uninterrupted during grid outages. Thanks to its ability to handle 150% peak output overloading in backup mode and 2× AC oversizing, the PH1100 EU delivers outstanding performance in demanding scenarios. ]]> ✅ Key Features
🔋 Supports 150–800V High-Voltage Batteries: Enhanced efficiency and system scalability
⚡ Max. PV Input 1000V, 1.5× PV Oversizing Supported: Maximize solar harvest
🔌 String Current up to 40A: Ideal for modern high-output PV modules
🔄 <10ms UPS Switching Time: Seamless backup for essential loads
💪 150% Peak Output Overload in Backup Mode: Reliable surge capacity
🧠 Smart Energy Management: Supports 6 programmable time-of-use segments
🌐 Built-in Anti-feed-in Function: Compliant with grid export control policies
🔗 Supports Parallel Connection and Generator Input
🔋 Compatible with 280Ah & 315Ah Battery Systems
🔄 100% Three-Phase Unbalanced Load Support
🚨 AFCI (Optional) & Rapid Shutdown Ready: Enhanced safety
📡 Remote Monitoring & Firmware Upgrade via WiFi
🛠 Configurable Operation Modes for On-Grid, Off-Grid, and Backup Use

Recommended for:
Small industrial and commercial buildings
Rural energy projects or mini-grid deployment
Multi-tenant residential buildings or microgrids
EV charging stations with integrated PV + storage systems

MODEL PH11-20KL3-EU-HV PH11-30KL3-EU-HV PH11-50KL3-EU-HV
Rated power 20000W 30000W 50000W
PV INPUT
Max. Dc Input Power 30KW 45KW 75KW
Max. PV Voltage 1000V
Rated DC input Voltage 620V
DC Input Voltage Range 150-1000V
MPPT Voltage Range 150-850V
Full MPPT Range 500-850V
Start-up Voltage 160V
Max.DC input Current 32A*2 40A*2 40A*4
Max.Short Current 48A*2 60A*2 48A*4
No. of MPPT Tracker/Strings 2/4 2/4 4/8
BATTERY PORT
Battery Nominal Voltage 500V 550V 500V
Battery Voltage Range 150-800V
Max. Charge/Discharge Current 50A 60A 120A
Max. Charge/Discharge Power 20KW 30KW 50KW
Charging Curve 3 Stages
Compatible Battery Type Li-ion / Lead-acid / Sodium metal chloride battery
AC GRID
Nominal AC Output Power 20KW 30KW 50KW
Max. AC Input/Output Power 30KVA/22KVA 45KVA/33KVA 100KVA/55KVA
Max. AC Output Current 32A 48A 83.38A
Nominal AC Voltage 230V/400V
Nominal AC Frequency 50Hz/60Hz
Power Factor 1(-0.8-0.8) adjustable
Current THD <3%
AC LOAD OUTPUT (BACK-UP)
Nominal Output Power 20000VA 30000VA 55000VA
Nominal Output Voltage 230V/400V
Nominal Output Frequency 50Hz/60Hz
Nominal Output Current 29A 43.5A 72.5A
Peak Output Power 22000VA, 60s 33000VA, 60s 55000VA, 60s
THDV (with linear load) 3%
Switching Time <10ms
EFFICIENCY
Europe Efficiency 97.80% 98.10% 98.30%
Max. Efficiency 98.30% 98.50% 98.60 %
Battery Charge/Discharge Efficiency 98.00% 98.00% 99.00%
PROTECTION
Reverse Polarity Protection Yes
Over Current/ Voltage Protection Yes
Anti-islanding Protection Yes
AC Short-ciruit Protection Yes
Leakage Current Detection Yes
Ground Fault Monitoring Yes
Grid Monitoring Yes
Enclosure Protect Level IP65 IP65 IP66
AC/DC surge protection Type II
GENERAL DATA
Dimensions (W x H x D, mm) 558*535*260 979*610*310
Weight (kg) 29 36 70
Topology Transformerless
Cooling Concept Intelligent Fan
Relative Humidity 0-100%
Operating Temperature Range (°C) -25°C to 60°C
Operating Altitude (m) <4000m
Standby Consumption (W) <100W
Display & Communication Interfaces LCD, LED, RS485, CAN, Wi-Fi, GPRS, 4G
CERTIFICATION & STANDARDS
EN50549-1, IEC62109-1, IEC62109-2, EN61000-6-3
]]> PH1100 EU Series (High Voltage 5–25kW) https://www.mustpower.com/product/ph1100-eu-series-high-voltage-5-25kw/ Wed, 11 Jun 2025 07:52:26 +0000 https://www.mustpower.com/?post_type=product&p=25076 ⚡ HIGH VOLTAGE THREE PHASE HYBRID SOLAR INVERTER 5–25kW | 160–700V High Voltage Battery | Max. PV 1000V The PH1100 EU Series (5–25kW) is a next-generation three-phase hybrid inverter designed for high-demand residential, commercial, and light industrial solar-plus-storage systems. It supports high-voltage lithium battery connections (160–700V), enabling greater system efficiency, thinner cabling, and reduced energy losses. Tailored for large rooftop PV arrays, multiple orientations, and complex load conditions, it offers full compatibility with diesel generators, AC coupling, and parallel operation of up to 9 units. This flexibility makes it ideal for building resilient energy infrastructures.]]> ✅ Key Features
🔋 High-Voltage Battery Compatibility (160–700V): Higher efficiency and faster response
⚡ Max. PV Input 1000V: Ideal for large and long string configurations
🔄 Max. Charge/Discharge Current: 50A
🧠 Self-Adaptive BMS Communication: Supports leading high-voltage battery brands
🧊 IP66 Protection: Built to last in both indoor and outdoor environments
🎛 Colorful Touch Screen: Intuitive operation and system visibility
🔗 Supports Multiple Batteries in Parallel: Expand capacity seamlessly
🕒 6 Time Periods for Charging/Discharging: Flexible load shifting
🧩 Max. 9 Units in Parallel: Scalable on-grid and off-grid deployment
🔌 AC Coupling: Retrofit compatibility with existing PV systems
⚙ Diesel Generator Compatible: Store generator energy directly without external converters
🔄 100% Three-Phase Unbalanced Load Support: Each phase delivers up to 50% of rated output
📡 WiFi Monitoring + Remote Firmware Upgrade: Smart management from anywhere

Best suited for:
Large residential villas or multi-family homes
Small to medium commercial PV energy storage systems
Light industrial facilities with unbalanced load conditions
Microgrid projects or hybrid diesel-PV storage systems

MODEL PH11-5KL3-EU-HV PH11-6KL3-EU-HV PH11-8KL3-EU-HV PH11-10KL3-EU-HV PH11-12KL3-EU-HV PH11-15KL3-EU-HV PH11-20KL3-EU-HV PH11-25KL3-EU-HV
Rated power 5000W 6000W 8000W 10000W 12000W 15000W 20000W 25000W
BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage range 160-700V
Charging curve 4-stage adaptive with maintenance/Equalization
Charging Strategy for Li-ion Battery Self-adaption to BMS
Over-current protection Yes
Over-temperature protection Yes
Maximum charging/discharging current 30A 30A 37A 37A 37A 37A 37A 50A
PV STRING INPUT DATA
Max. DC Input Power 6500W 7800W 10400W 13000W 15600W 19500W 26000W 32500W
Rated PV Input Voltage 600V
Maximum DC voltage 1000V
Start-up Voltage 180V
Minimum voltage for grid connection 200V
Full Load DC Voltage Range 162~800V 195~800V 260~800V 325~800V 339~800V 423~800V 565~800V 480~800V
MPPT voltage range 150~800V
Maximum input current 20A+20A 20A+20A 20A+20A 20A+20A 26A+20A 26A+20A 26A+20A 26A+26A
No.of MPP Trackers 2/4
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/ Output Power 5000W 6000W 8000W 10000W 12000W 15000W 20000W 25000W
Max. AC Input/ Output Power 5000W 6000W 8000W 10000W 12000W 15000W 20000W 25000W
Max. AC Input/ Output Current 8.4/8A 10/9.6A 13.4/12.8A 16.7/16A 18.2/17.4A 22.8/21.8A 30.4/29A 22.8/212.8A
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Rated Input/Output Voltage 230/380VAC
Rated Input/Output Grid Frequency Range 60Hz±5Hz/50Hz±5Hz
Grid Type Three Phase
Total Harmonics Current Distortion (THDi) <3% (of nominal power)
Rated output power factor 1
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
Euro Efficiency 99.5%
PROTECTION
Integrated Islanding protection, PV input polarity reverse protection, insulationresistance detection, surge protection,leakage current monitoringprotection,output current protection, output short circuit protectionoutput overvoltage protection
Surge Protection DC Type III/AC Type III
Overvoltage Category DC Type II/AC Type III
GENERAL DATA
Operating Temperature Range (°C) -25°C to +60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤55dB
Communication USB/ WI-FI/ Ethernet(optional)
Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
Package Dimension (W*H*D)(mm) 567*816*404
N.W(kg) 38
G.W(kg) 42
Protection Degree IP66
Installation Style Wall-mounted
Warranty 5 Years
CERTIFICATION & STANDARDS
NBT32004-2013/EN50549
]]> PH1100 EU Series (Three Phase 13–16kW) https://www.mustpower.com/product/ph1100-eu-series-three-phase-13-16kw/ Wed, 11 Jun 2025 07:43:28 +0000 https://www.mustpower.com/?post_type=product&p=25074 ⚡ THREE PHASE HYBRID SOLAR INVERTER 13–16kW | 48V Lithium Battery | Max. PV 800V The PH1100 EU Series (13–16kW) is a high-performance three-phase hybrid inverter, expertly engineered for residential and small commercial applications that demand powerful, reliable, and flexible energy storage solutions. With its low-voltage 48V battery system, bidirectional power flow, and transformer isolation design, this series offers superior safety and compatibility with both lithium and lead-acid batteries. It delivers a stable 380/400V three-phase output and supports 100% unbalanced loads, making it ideal for diverse real-world electrical demands. ]]> ✅ Key Features
🔄 On/Off-Grid Functionality: Seamlessly switch or combine operation modes
💡 100% Unbalanced Three-Phase Output: Perfect for uneven residential or commercial loads
🔋 Max. 320A Charging/Discharging Current: For rapid battery cycling and high-power usage
🔗 Supports Multiple Batteries in Parallel: Enhanced scalability
🔌 AC Coupling Compatible: Retrofit existing solar installations with ease
🧊 48V Low-Voltage System: With transformer isolation for added safety
💧 IP66 Protection: Dust-tight and water-resistant enclosure for outdoor use
🕒 Time-of-Use Programming: Set up to 6 time segments for smart energy scheduling
⚙ Diesel Generator Compatible: Store surplus genset energy efficiently
📡 WiFi Monitoring: Real-time insights into energy generation, storage, and consumption
🧩 Up to 6 Units Parallel: Expand capacity for larger energy demands

Ideal for:
Homes with three-phase electrical systems
Smart microgrids and energy-sharing networks
Small commercial solar + storage projects
Off-grid resorts, farms, and remote area installations

MODEL PH11-13KL3-EU PH11-14KL3-EU PH11-15KL3-EU PH11-16KL3-EU
Rated power 13000W 14000W 15000W 16000W
BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~64V
Charging curve 4-stage adaptive with maintenance/Equalization
Charging Strategy for Li-lon Battery Self-adaption to BMS
Over-current protection/ Over-temperature protection Yes / Yes
Maximum charging/discharging power 13000W 14000W 15000W 16000W
Maximum charging/discharging current 260A 280A 300A 320A
PV STRING INPUT DATA
Max. DC Input Power 16900W 18200W 19500W 20800W
Rated PV Input Voltage 370V
Maximum DC voltage 800V
Start-up Voltage 125V
Minimum voltage for grid connection 200V
Full Load DC Voltage Range 352~650V 379~650V 406~650V 433~650V
Enter high voltage error recovery point 800V
MPPT voltage range 150~800V
Maximum input current 32A/16A 32A/16A 32A/16A 32A/16A
No.of MPP Trackers 3 3 3 3
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/ Output Power 13000W 14000W 15000W 16000W
Max AC Input/ Output Power 13000W 14000W 15000W 16000W
AC Input/ Output Rated Current 19.7A/18.8A 21.2A/20.3A 22.7A/21.7A 24.2A/23.2A
Max. Three-phase Unbalanced Output Current 29.5A/28.2A 31.8A/30.4A 34A/32.5A 36.3A/34.8A
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Rated Input/Output Voltage 230/380VAC
Rated Input/Output Grid Frequency Range 60Hz±5Hz/50Hz±5Hz
Grid Type Three Phase
Total Harmonics Current Distortion (THDi) <3% (of nominal power)
DC Current Injection <0.5% In
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
Euro Efficiency 99.5%
PROTECTION
Integrated Islanding protection, PV input polarity reverse protection, insulationresistance detection, surge protection,leakage current monitoringprotection,output current protection, output short circuit protectionoutput overvoltage protection
Surge Protection DC Type III/AC Type III
Overvoltage Category DC Type II/AC Type III
GENERAL DATA
Operating Temperature Range (°C) -25°C to +60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤55dB
Communication with BMS RS485/CAN
Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
Package Dimension (W*H*D)(mm) 567*816*404
N.W(kg) 38
G.W(kg) 42
Protection Degree IP66
Installation Style Wall-mounted
Warranty 5 Years
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
CERTIFICATION & STANDARDS
NBT32004-2013
]]> PH1100 EU-G2 Series (3-8kW) https://www.mustpower.com/product/ph1100-eu-g2-series-3-8kw/ Fri, 30 May 2025 07:29:09 +0000 https://www.mustpower.com/?post_type=product&p=25019 HYBRID SOLAR INVERTER Smart Power Control for European Homes & Small Businesses The PH1100 EU-G2 Series is a new-generation single-phase hybrid solar inverter designed for residential and small commercial energy systems. With 3–8KW output power, it seamlessly integrates solar PV, battery storage, diesel generator, and utility grid into a unified smart energy hub. Built to support both on-grid and off-grid operation, this inverter features advanced power management, robust protection, and an intuitive user interface. Whether you’re retrofitting an existing system or building a new one, the PH1100 EU-G2 delivers flexible and future-ready energy independence.]]> ⚙ Key Specifications
Rated Output Power: 3-8KW
Battery Voltage Range: 40V ~ 64V
Max PV Voltage: 550V
Max PV Input Power: up to 12KW (for 8KW model)

✅ Core Features
■ IP66 protection, suitable for indoor and outdoor installations
■ 4.3-inch colorful touch LCD for a clear and interactive display
■ Supports AC coupling, perfect for retrofitting existing PV systems
■ Up to 9 units parallel for both on-grid and off-grid use
■ Max. charge/discharge current: 190A for faster energy conversion
■ 6 programmable time periods for battery charge/discharge
■ Compatible with diesel generators for additional backup
■ Built-in WiFi for mobile monitoring and remote updates
■ Supports self-consumption first, backup, and time-of-use modes
■ Seamless switching (less than 10ms) for uninterrupted power supply

⚡ Ideal For
• Residential PV systems in European voltage environments
• Hybrid solar + storage setups
• Smart homes with energy independence goals
• Small businesses needing backup + optimization

The PH1100 EU-G2 makes solar smarter — empowering you to control your energy, reduce your electricity bills, and move toward a cleaner, self-sufficient future.

MODEL PH11-3KL1-EU-G2 PH11-3.6KL1-EU-G2 PH11-4KL1-EU-G2 PH11-4.6KL1-EU-G2 PH11-5KL1-EU-G2 PH11-6KL1-EU-G2 PH11-7KL1-EU-G2 PH11-7.6KL1-EU-G2 PH11-8KL1-EU-G2
BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~64V
Charging curve 3-stage adaptive with maintenance/Equalization
Charging Strategy for Li-lon Battery Self-adaption to BMS
Over-current protection/ Over-temperature protection Yes / Yes
Maximum charging/discharging power 3000W 3600W 4000W 4600W 5000W 6000W 7000W 7600W 8000W
Maximum charging/discharging current 75A 90A 100A 110A 120A 135A 175A 190A 190A
PV STRING INPUT DATA
Max. DC Input Power 4500W 5400W 6000W 6900W 7500W 9000W 10500W 11400W 12000W
Maximum DC voltage 550V
Start-up Voltage 125V
Full Load DC Voltage Range 250-500V 300-500V 167-500V 192-500V 208-500V 250-500V 165-500V 179-500V 188-500V
Rated PV Input Voltage 370V
Minimum voltage for grid connection 150V
Enter high voltage error recovery point 550V
Maximum input current 18A 18A 18A+18A 18A+18A 18A+18A 18A+18A 32A+32A 32A+32A 32A+32A
No.of MPP Trackers 1 1 2 2 2 2 2 2 2
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/Output Active Power 3000W 3600W 4000W 4600W 5000W 6000W 7000W 7600W 8000W
Max. AC Input/Output Apparent Power 3300VA 3960VA 4400VA 5060VA 5500VA 6600VA 7700VA 8360VA 8800VA
Rated AC Input/Output Current 13A 15.6A 17.3A 20A 21.7A 26A 30.4A 33A 34.7A
Max. AC Input/Output Current 14.3A 17.2A 19.1A 22A 23.9A 28.6A 34.5A 36.3A 38.3A
Max. Continuous AC Passthrough (grid to load) 35A 40A 50A
Rated Input/Output Voltage/Range 220/230/240VAC
Rated Input/Output Grid Frequency/ Range 60Hz±5Hz/ 50Hz±5Hz
Rated output power factor 1
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi) <3%
Grid Type Single phase
DC Current Injection <0.5%
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
MPPT Efficiency >99%
PROTECTION
Integrated Islanding protection, Output overcurrent protection, Output overvoltage protection, PV input polarity reverse
protection, DC Switch (optional), Ground Fault Sensing, leakage current monitoringprotection
Surge Protection DC Type III/AC Type III
Overvoltage Category DC Type II/AC Type III
GENERAL DATA
Operating Temperature Range (°C) -25°C~+60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤50dB
Altitude 3000m, >3000mDerating
Topology Battery-side transformer isolation, PV-side non-transformer isolation
Communication USB/ WiFi/ Enternet(optional)
Display 4.3-inch touch screen
Protection Degree IP66
Installation Style Wall-mounted
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 360*500*238
Package Dimension (W*H*D)(mm) 622*479*363
N.W(kg) 22
G.W(kg) 25
Warranty 5 year
CERTIFICATION & STANDARDS
NBT32004-2013/EN50549
]]> PH1900 EXP Series (6-12kW) https://www.mustpower.com/product/ph1900-exp-series-6-12kw/ Wed, 04 Dec 2024 07:04:23 +0000 https://www.mustpower.com/?post_type=product&p=24822 Dual Output Hybrid Solar Inverter PH1900 EXP is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PH1900 EXP Series can run without battery. The Maximum PV input voltage can reach 500V and MPPT voltage range is 90~450Vdc, built-in two MPPTs solar charge controller, which can help customers make full use of solar energy.]]> ■ Dual output for smart load management
■ Smart color LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in Two MPPTs solar charge controller
■ Wide MPPT voltage range is 90~450V, the maximum PV input voltage can reach 500V (450V for parallel)
■ Can provide the power to the load without battery
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ With BMS lithium battery communication function
■ With AC/PV lithium battery activation function
■ Support USB, RS485 monitoring function
■ Parallel operation up to 6 units
■ WIFI remote monitoring

MODEL PH19-6248 EXP PH19-8048 EXP PH19-10048 EXP PH19-11048 EXP PH19-12048 EXP
Default Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 6200VA/6200W 8000VA/8000W 10000VA/10000W 11000VA/11000W 12000VA/12000W
Surge Power 12400W 16000W 20000W 22000W 24000W
Waveform Pure Sine Wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 92%
Transfer Time 10ms(UPS / VDE4105) / 20ms(APL)
AC INPUT
Voltage 230VAC
Max AC Input Voltage 300VAC
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VDE)
Frequency Range 50Hz / 60Hz (Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 500VDC (450V for parallel)
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 4000W*2 4000W*2 5000W*2 6000W*2 6000W*2
Maximum PV Input Current 18A*2 18A*2 27A*2(40A max) 27A*2(40A max) 27A*2(40A max)
PV Array MPPT Voltage Range 90~450VDC (90~430VDC for parallel)
Min Battery Voltage For PV charge 34VDC
Maximum Solar Charge Current 120A 120A 150A 150A 150A
Maximum AC Charge Current 100A 120A 150A 150A 150A
Maximum Charge Current 120A 120A 150A 150A 150A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D) 425*473*145mm 425*527*145mm
Package Dimension (W*H*D) / / / / /
N.W (kg) / 17.4 17.4 / 17.6
G.W (kg) / / / / /
OTHER
Humidity 5% to 95% Relativ Humidity (Non-condensing)
Operating Temperature Range 0°C~50°C
Storage Temperature Range -15°C~60°C
Warranty 2 year
CERTIFICATION & STANDARDS
CE
]]> PH1100 EU Series (Single Phase 5–10kW) https://www.mustpower.com/product/ph1100-eu-series-single-phase-5-10kw/ Tue, 12 Nov 2024 08:55:34 +0000 https://www.mustpower.com/?post_type=product&p=24775 ⚡ SINGLE PHASE HYBRID SOLAR INVERTER 5–10kW | 48V Lithium Battery | Max. PV 600V The PH1100 EU Series is a next-generation single-phase hybrid solar inverter designed to empower homes and small commercial setups with greater energy independence and smart power management. Integrating solar generation, battery storage, and grid connectivity, it enables users to optimize energy usage and minimize electricity bills—especially under time-of-use or demand-based utility pricing. With support for up to 16 units in parallel, robust AC coupling options, and compatibility with a wide range of low-voltage lithium batteries, this series provides the flexibility and performance needed for both new installations and system retrofits.]]> ✅ Key Features
🌈 Colorful Touch LCD: Intuitive interface for easy configuration and monitoring
💧 IP66 Protection: Fully weatherproof for indoor & outdoor installations
🔋 Max. Charging/Discharging Current 220A: Supports high power battery banks
♻ AC Coupling: Seamless upgrade for existing solar systems
🔗 Up to 16 Units in Parallel: On-grid and off-grid operation supported
🔄 Battery Auto-Adaptation: Supports 48V lithium batteries with BMS auto-detection
📅 6 Programmable Time Periods: Smart battery charge/discharge scheduling
⚙ Diesel Generator Support: Energy storage from genset input
📡 WiFi Monitoring: Real-time energy data via mobile/web apps

Ideal for:
Residential PV + Battery Systems
Smart Home Energy Upgrades
Existing Solar System Retrofits
Regions with Time-of-Use Tariffs or Unstable Grids

MODEL PH11-5KL1-EU PH11-6KL1-EU PH11-8KL1-EU PH11-10KL1-EU
Rated power 5000W 6000W 8000W 10000W
BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~60V
Charging curve 3-stage adaptive with maintenance/Equalization
Charging Strategy for Li-lon Battery Self-adaption to BMS
Over-current protection/ Over-temperature protection Yes / Yes
Maximum charging/discharging power 5000W 6000W 8000W 10000W
Maximum charging/discharging current 120A 150A 190A 220A
PV STRING INPUT DATA
Max. DC Input Power 6500W 7800W 10400W 13000W
Maximum DC voltage 600V
Start-up Voltage 125V
Full Load DC Voltage Range 150~540V
Rated PV Input Voltage 370V
Minimum voltage for grid connection 150V
Enter high voltage error recovery point 600V
Maximum input current 16A/16A 16A/16A 32A/16A 32A/16A
No.of MPP Trackers 2 2 2 2
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/Output Active Power 5000W 6000W 8000W 10000W
Max. AC Input/Output Apparent Power 5500VA 6600VA 8800VA 11000VA
Rated AC Input/Output Current 21.7A 26A 34.7A 43.4A
Max. AC Input/Output Current 23.9A 28.6A 38.2A 47.8A
Max. Continuous AC Passthrough (grid to load) 32.6A 39.1A 52.1A 65.2A
Rated Input/Output Voltage/Range 230VAC
Rated Input/Output Grid Frequency/Range 60Hz±5Hz/ 50Hz±5Hz
Rated output power factor 1
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi) <3%
Grid Type Single phase
DC Current Injection <0.5%
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
MPPT Efficiency 99.5%
PROTECTION
Integrated Islanding protection, Output overcurrent protection, Output overvoltage protection, PV input polarity reverse protection, DC Switch (optional), Ground Fault Sensing, leakage current monitoringprotection
Surge Protection DC Type III/AC Type III
Overvoltage Category DC Type II/AC Type III
GENERAL DATA
Operating Temperature Range (°C) -25°C~+60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤50dB
Altitude 3000m, >3000mDerating
Topology Battery-side transformer isolation, PV-side non-transformer isolation
Communication USB/ WiFi/ Enternet(optional)
Display 4.3-inch touch screen
Protection Degree IP66
Installation Style Wall-mounted
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
Package Dimension (W*H*D)(mm) 816*404*567
N.W(kg) 38 (Excluding Connectors and Brackets)
G.W(kg) 42
Warranty 5 Year
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
CERTIFICATION & STANDARDS
NBT32004-2013
]]> PH1800 TLV Series (AC:110/220V 6KW) https://www.mustpower.com/product/ph1800-tlv-series-ac110-220v-6kw/ Sun, 29 Sep 2024 02:31:47 +0000 https://www.mustpower.com/?post_type=product&p=24593 High Frequency On/Off Hybrid Solar Inverter PV 250V | MPPT 80A | DC 48V This split phase solar inverter PH1800 TLV series, capacity 6KW, DC 48V, it’s applicable to 110VAC/120VAC markets demands, which has AC output of single phase 110VAC/120V, split phase 220V/240V; In LCD display, you can set output voltage, frequency, charging voltage, charging current to design best use based on different loads applications; meanwhile, it has built-in two 80A MPPT solar charge controllers, you can take use of sunshine freely and save electricity bills.]]> ■ Pure sine wave solar inverter
■ Output power factor 1
■ Built-in two 80A MPPT solar charge controllers
■ WIFI remote monitoring (optional)
■ Acid or Lithium Battery Select
■ CAN/RS485 communication for BMS
■ Compatible to generator

MODEL PH18-6048 TLV
Nominal Battery System Voltage 48VDC
INVERTER OUTPUT
Rated Power 6000W
Surge Power 12000VA
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 120VAC/240VAC (L1/L2)
Inverter Efficiency(Peak) 90%~93%
Transfer Time 10ms (UPS / UL) 20ms (APL)
AC INPUT
Voltage 240VAC (L1/L2/N)
Selectable Voltage Range 214~264VAC(UL)
Frequency Range 50Hz / 60Hz(Auto sensing)
BATTERY
Normal voltage 48VDC
Floating Charge Voltage 54.8VDC
Overcharge Protection 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 250V
Maximum Solar Charge Current 80A/80A
PV Array MPPT Voltage Range 60~200VDC
PV Input Power 4000W/4000W
Maximum Efficiency 98%
Maximum AC Charge Current 60A/60A
Maximum Charge Current 280A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 318*560*249
Package Dimension (W*H*D)(mm) 678*345*420
N.W(kg) 21.5
G.W(kg) 24
OTHER
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature -10°C~50°C
Storage Temperature -15°C~60°C
Standard Warranty 2years
CERTIFICATION & STANDARDS
CE-LVD (IEC62109-1, EN IEC62109-2); UKCA-(BS EN 62109-1, BS EN 62109-2)
]]> PH1100 US Series (Split Phase 5-10KW) https://www.mustpower.com/product/ph1100-us-series-split-phase-5-10kw/ Wed, 26 Jun 2024 03:54:36 +0000 https://www.mustpower.com/?post_type=product&p=24459 Split Phase Hybrid Solar Inverter | AC 240/120V | DC 48V | PV 370V PH1100 US is brand new split phase hybrid inverter with low battery voltage 48V, ensuring system safe and reliable. With compact design and highpower density, this series supports 1.3 DC/AC ratio, saving device investment. It’s applicable to 110VAC/120VAC markets demands, which matches AC 110VAC/120V single phase, or two phase 220V/240V; Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remotely control, x1 DRM port, which makes the system smart and flexible.]]> ■ 100% unbalanced output, each phase max. output up to 50% rated power
■ Max. 6 pcs parallel for on-grid and off-grid operation
■ AC couple to retrofifit existing solar system
■ Support multiple batteries parallel
■ Max. charging/discharging current of 220A
■ Support storing energy from diesel generator
■ 48V low voltage battery, transformer isolation design
■ IP66 water-proof and dust-proof
■ “Time of use” function: a maximum of 6 time segments can be set
■ Wifi monitoring

MODEL PH11-5KL2-US PH11-6KL2-US PH11-8KL2-US PH11-10KL2-US
Rated power 5000W 6000W 8000W 10000W
BATTERY INPUT DATA
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~64V
Charging curve 3-stage adaptive with maintenance/Equalization
Charging Strategy for Li-lon Battery Self-adaption to BMS
Over-current protection/ Over-temperature protection Yes / Yes
Maximum charging/discharging power 5000W 6000W 8000W 10000W
Maximum charging/discharging current 110A 130A 170A 220A
PV STRING INPUT DATA
Max. DC Input Power 6500W 7800W 10400W 13000W
Maximum DC voltage 600V
Start-up Voltage 125V
Full Load DC Voltage Range 150~500V
Rated PV Input Voltage 370V
Minimum voltage for grid connection 150V
Enter high voltage error recovery point 600V
Maximum input current 16A/16A 16A/16A 32A/16A 32A/16A
No.of MPP Trackers 2 2 2 2
Input terminal type H4/MC4
AC INPUT/OUTPUT DATA
Rated AC Input/ Output Power 5000W 6000W 8000W 10000W
Max AC Input/ Output Power 5000W 6000W 8000W 10000W
AC Input/ Output Rated Current 20.8A/19.2A 25A/23A 33.3A/30.7A 41.6A/38.4A
Rated Input/Output Voltage/Range 120V/240V:208V
Rated Input/Output Grid Frequency/Range 60Hz±5Hz/ 50Hz±5Hz
Rated output power factor 1
Power Factor Adjustment Range 0.8 leading to 0.8 lagging
Total Harmonics Current Distortion (THDi) <3%
Grid Type Split Phase
DC Current Injection <0.5%
EFFICIENCY
Max. Efficiency 97.5%
Euro Efficiency 96.5%
MPPT Efficiency 99.5%
PROTECTION
Integrated Islanding protection, Output overcurrent protection, Output overvoltage protection, PV input polarity reverse protection, DC Switch (optional), Ground Fault Sensing, leakage current monitoringprotection
Surge Protection DC Type III/AC Type III
Overvoltage Category DC Type II/AC Type III
GENERAL DATA
Operating Temperature Range (°C) -25°C~+60°C, >45°C Derating
Cooling Fan cooling
Noise (dB) ≤50dB
Altitude 3000m, >3000mDerating
Topology Battery-side transformer isolation, PV-side non-transformer isolation
Communication USB/ WiFi/ Enternet(optional)
Display 4.3-inch touch screen
Protection Degree IP66
Installation Style Wall-mounted
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 446*692*260 (excluding connectors and racks)
Package Dimension (W*H*D)(mm) 816*404*567
N.W(kg) 38
G.W(kg) 42
Warranty 5 Year
the Warranty Period Depends the Final Installation Site of Inverter, More Info Please Refer to Warranty Policy
CERTIFICATION & STANDARDS
NBT32004-2013
]]> PH1900 EXP Series (4/6KW) https://www.mustpower.com/product/ph1900-exp-series-4-6kw/ Fri, 24 May 2024 07:54:24 +0000 https://www.mustpower.com/?post_type=product&p=24298 On/Off Grid Hybrid Solar Inverter DC 24/48V | PV 500V | MPPT 100/120A PH1900 EXP is a multi-function inverter/charger, combining functions of inverter, MPPT solar charger and battery charger to offer uninterruptible power support in portable size. PH1900 EXP Series can run without battery. The Maximum PV array open circuit voltage can reach 500V and MPPT voltage is 90~430V, which can help customers make full use of solar energy.]]> ■ Pure sine wave output
■ Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
■ Built-in MPPT solar charge controller
■ MAX PV Array Open Circuit Voltage: 500V
■ Combining solar system, AC utility, and battery power source to supply continuous power
■ Overload, short circuit and Deep discharge protection
■ Cold start function
■ Support USB, RS485 monitoring function
■ Parallel operation with up to 3 units
■ WIFI remote monitoring (optional)
■ With BMS lithium battery communication function
■ With AC/PV lithium battery activation function
■ Dual outputs for smart load management

MODEL PH19-4024 EXP PH19-6048 EXP
Nominal Battery System Voltage 24VDC 48VDC
INVERTER OUTPUT
Rated Power 4000VA/4000W 6000VA/6000W
Surge Power 8000W 12000W
Waveform Pure sine wave
AC Voltage Regulation (Batt.Mode) 230VAC±5%(Setting)
Inverter Efficiency(Peak) 90%
Transfer Time 10ms (UPS / VDE4105) / 20ms (APL)
AC INPUT
Voltage 230VAC±5%
Selectable Voltage Range 170~280VAC(UPS) / 90~280VAC(APL) / 184~253VAC(VED4105)
Frequency Range 50Hz / 60Hz(Auto sensing)
BATTERY
Normal voltage 24VDC 48VDC
Floating Charge Voltage 27.4VDC 54.8VDC
Overcharge Protection 30VDC 60VDC
SOLAR CHARGER & AC CHARGER
Maximum PV Array Open Circuit Voltage 500VDC
Maximum PV input Current 18A 27A
Charging Algorithm 3-Step (Flooded Battery, AGM / GEL / LEAD Battery), 4-Step (Li)
Maximum PV Array Power 5000W 6000W
PV Array MPPT Voltage Range 90~430 VDC 120~430 VDC
Maximum Solar Charge Current 100A 120A
Maximum AC Charge Current 80A 100A
Maximum Charge Current 100A 120A
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 322*486*134 309*505*147
Package Dimension (W*H*D)(mm) 600*230*420 603*260*400
N.W(kg) 10.6 12.9
G.W(kg) 12 13.8
OTHER
Humidity 5% to 95% Relative humidity (Non-condensing)
Operating Temperature 0°C~50°C
Storage Temperature -15℃ ~60℃
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3:2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011)
EN IEC62368-1:2020+A11:2020 EN IEC62368-1:2018
Rohs-(2011/65/EUand2015/863/EU)
]]> PH1100 LV Series (AC120V: 3.6/4KW) https://www.mustpower.com/product/ph1100-lv-series-ac120v-3-6-4kw/ Wed, 24 Apr 2024 03:31:31 +0000 https://www.mustpower.com/?post_type=product&p=24152 High Frequency On/Off Hybrid Solar Inverter 3.6/4KW | AC 120V | PV 500V | IP65 This is a flexible and intelligent energy storage solar inverter with a wide range of MPPT Voltage. Combining functions of off grid and on grid. This hybrid solar inverter can power all kinds of appliances in home or office, and can also be used in power stations.]]> ■ Multiple operation modes: Grid-tie,off grid with storage backup
■ IP65 water-proof and dust-proof
■ MPPT voltage range 120-500V
■ Support LCD display&Smart LCD setting
■ Available Export control CT sensor function
■ Multiple communications:USB,RS485,GPRS and wifi etc
■ Full protection function:Over-voltage,over-frequency, over-current, over-temperature,and AC short-circuit automatic protection
■ Intelligent BMS battery management function
■ Fanless low-noise design
■ Wifi monitoring

MODEL PH11-3648 LV PH11-4048 LV
Rated Power 3600W 4000W
Nominal Battery System Voltage 48V
PV INPUT(DC)
Maximum recommended DC power 4600W 5200W
Nominal DC operating voltage 360V
Maximum DC voltage 500V
MPPT voltage range 120V~500V
Maximum input current 15A / 15A
No.of MPP tracker 2
Strings per MPP tracker 1
INVERTER INPUT/ OUTPUT(AC)
Nominal AC input/ output power 3600W 4000W
Nominal input/ output voltage; range 110/120/130V; 90~140V
AC grid frequency; range 50/60Hz; 45~55/55-65Hz
Nominal input/ output current 30A 34A
Maximum input/ output current 33A 36A
Inrush current (spike/duration) 72A/5.2us
Total harmonic distortion i(THDi) <3%
Power factor at rated power 1
Displacement power factor 0.8leading ～ 0.8lagging
Grid type Single phase
BATTERY MODE OUTPUT(AC)
Output Rated Power 3600W 4000W
Nominal output voltage; accuracy range 120±1%
Output ferequency; accuracy range 50/60Hz (optional)±0.2%
Output rated current 30A 34A
Output waveform Pure sine wave
Peak power 5400W,10s 6000W,10s
Total harmonic distortion v (linear load) <3%
BATTERY & CHARGER
Battery type Lead-acid battery / Lithium battery
Battery voltage 48V
Battery voltage range 40~60V
Charging curve 3-stage adaptive with maintenance
Protection Over-current protection / Over-temperature protection
Maximum charging power 3600W 4000W
Maximum charging currernt 75A 85A
EFFICIENCY
Maximum efficiency 97.1%
Euro-efficiency 96.5%
MPPT efficiency 99.8%
PROTECTION DEVICES
DC switch rating for each MPPT; Grid monitoring; Output over current protection; Output overvoltage protection-varistor; Ground fault monitoring; Integrated all-pole sensitive leakage current
MECHANICAL SPECIFICATIONS
Machine Dimension (W*H*D)(mm) 420*480*215
Package Dimension (W*H*D)(mm) 610*324*595
N.W(kg) 30
G.W(kg) 32
GENERAL
DC connection H4 / MC4
AC connection Terminal Block
Display LED+LCD
Communication interfaces Wi-Fi / USB / GPRS / RS485
Ingress protection rating IP65
Humidity 0~95% RH(No codensing)
Operating temperature range -20°C+60°C With derating above 45°C
Cooling concept Natural
Altitude <3000m
Standard Warranty 5years
CERTIFICATION & STANDARDS
CE-EMC+LVD (EN6100-6-3: 2007, EN6100-6-1:2017+EN IEC62109-1:2010, EN IEC62109-2:2011); CE-LVD(EN62477-1:2022) IEC60529; EN50549-1:2019; Poland Type A, (NC RfG:2016, PSE:2018, PTPiREE:2021), C10/C11; UNE217001-2020; UNE217002-2020, NTS-631:2021 (Type A); G98+G99
]]>
